Longacre Computerscales 7263 Operating Instructions

QUICK START INSTRUCTIONS:

 Set up pads alongside car (they are interchangeable), connect cables marked RF, LR,
etc., turn on, warm up 1-2 minutes.
 Press ZERO if all 4 wheel weights are not at 0.
 Put car on scales in the center of the pad to prevent rolling off (for safety purposes put
car in gear or block wheels).
 All weights and % are computed and updated automatically. There is nothing more
you need to do.
To store in Memory hold the Mem Store button and push Memory 1 to 10. To recall push &
hold any Memory button.
When Low Battery light flashes plug in charger. Scale will run on charger. Full recharge takes 12-24 hours.
Recharge every 60 days.
Keep scales and pads clean and dry. Do not drop! Do not expose to strong static or magnetic fields.
OPERATING INSTRUCTIONS:
1) Set up scale pads next to the wheels.
Pads are calibrated to within 5/100 of 1% and can be marked RF, LR, etc. or used interchangeably.
2) Set up control box in a convenient place, uncoil cables and plug into pads.
Be sure the cables go to the correct location, RF, LR, etc. and route cables to avoid tripping.
3) Turn on box, warm up 1 minute and Zero as needed.
When you push the ZERO button you are defining that as zero weight: the car MUST be off the pads.
4) Lift car and place pads under the wheels.
The weight will be the same regardless of the location of the tire on the pad. It is a good idea to keep it near
the center to minimize the possibility of the
Ramps or a platen setup fixture may also be used. FOR SAFETY REASON DO NOT GO UNDER THE CAR WHEN IT
IS ON THE SCALES.
Longacre Racing Products – Computerscales® 7263
Monroe, WA ∙ 360 453 2030 ∙ www.longacreracing.com
Computerscales Model 7263
Operating Instructions
car rolling off the pad. Put the car in gear or block the wheels.
