Technical Parameters - Eagle Access Control Systems EAGLE Open User Manual

Supply voltage: 8-32V DC, 6-24V AC
Operating temperature range: -40°C –+85°C
Max. current consumption (@24V): 75 mA
Number of switched output(s):2
Output type: unfused relay contact(NO)
Max. loadcurrent onoutput(s):1A@24V DC, 0.5A@125VAC

TECHNICAL PARAMETERS

Max. switchedvoltage:125V AC, 60V DC
Number of open detection inputs:2
Input voltage short circuit protection: fuse(0.2A)
Size: 40x80x20 mm
Wirelesscommunication protocol:Bluetooth 4.0LE
RF carrier frequency:2.4GHz
RF TX power: +4dBm
