- Page 1 User and Installation Guide 2.4 GHz RangeBooster Transmitter...
- Page 2 User and Installation Guide Unpacking: Check that this package contains: One 2.4 GHz RangeBooster transmitter, one AC adapter. How to use the RangeBooster transmitter The RangeBooster transmitter can be used in situations where sufficient coverage cannot be achieved by the primary transmitter and works as a repeater in conjunction with the primary transmitter.
- Page 3 User and Installation Guide Step 1 Preparing the Data cable The RangeBooster transmitter requires a data connection with the primary transmitter. This data connection should be established by using a shielded coaxial cable which is fitted with two RCA connectors. This cable is not provided with this set and is available from your local video or satellite equipment dealer.
- Page 4 User and Installation Guide Step 3 Connecting the RangeBooster transmitter Install the data cable such that the cable length is minimized. Optimum performance will be achieved if the cable length is 30 ft or less. Connect the RangeBooster transmitter power input with the supplied AC adapter. Connect the data cable with the data input at the RangeBooster transmitter and the data output of the primary transmitter.
- Page 5 User and Installation Guide Step 4 Operating the RangeBooster transmitter As soon as valid data is received via the data input, the transmit light will light and the RangeBooster transmitter will broadcast a signal. When the primary transmitter goes into standby mode or if no valid audio signal is received anymore, the RangeBooster transmitter will go into standby mode after approximately 1 minute and the transmit light will go out.
- Page 6 RangeBooster transmitter transmitter Strong interference For more information, including a detailed troubleshooting guide, visit the Amphony web site at: www.amphony.com What to Do Check the data cable for short circuits and ensure that it is properly connected to the primary transmitter and to the...
-
Page 7: Technical Specifications
Data rate: > 3 Mbps Data Port Cable Impedance: 50 … 75 Ohms Data Port Tuning: 16 settings Data Port audio format: Amphony Data (connects with Amphony devices that provide a Data Out port) Copyright (C) 2003 Amphony. All rights reserved. -
Page 8: Limited Warranty
This warranty extends only to the original user of the equipment (“you”, ”your”) and is limited to the purchase price of each part. Amphony and it’s affiliated companies (”we”, ”our”, ”us”) warrant this RangeBooster transmitter against defects in materials or workmanship as follows.
