Summary of Contents for Amphony RX1
- Page 1 User and Installation Guide DIGITAL Wireless Audio Transmitter / Receiver Model TX1, RX1...
- Page 2 User and Installation Guide Unpacking: Check that this package contains: One audio transmitter, one audio receiver, two AC adapters, two audio cables. Connecting the transmitter With the transmitter, you can send music from your iPod / iPhone or from any audio source that either provides a line-level audio signal or amplified speaker level signal.
- Page 3 User and Installation Guide iPod AC adapter DC 9 V Power outlet Example: Transmitting music from an iPod Page 3...
- Page 4 User and Installation Guide Y adapter cable LINE OUT Audio Source AC adapter DC 9 V Power outlet Example: Connecting the transmitter to a line-level audio source Page 4...
-
Page 5: Speaker Out
User and Installation Guide Audio Source SPEAKER OUT AC adapter DC 9 V Power outlet Example: Connecting the transmitter to an amplified audio source Page 5... -
Page 6: Connecting The Receiver
User and Installation Guide Connecting the receiver The receiver connects to a line-in interface of an active speaker or external amplifier via the supplied RCA cable. If no line-in interface is available, the receiver can also be connected to other audio inputs by using an appropriate adapter. - Page 7 User and Installation Guide Pairing the transmitter and receiver In order for the transmitter and receiver to communicate, they need to be paired. To pair the transmitter and receiver, push the transmitter pairing button. The transmit light will start flashing. Next, push the pairing button of the receiver which is located on the bottom of the receiver.
- Page 8 User and Installation Guide Transmit Light Transmitter Pairing Button Transmitter volume control Receiver Pairing Button Receive Light Page 8...
- Page 9 User and Installation Guide Setting the transmitter volume control The transmitter perfroms advanced analog-to-digital transmission of the audio signal. In order to achieve maximum dynamic range and avoid clipping of the audio, the transmitter volume control must be adjusted to your audio source.
-
Page 10: Troubleshooting
User and Installation Guide Troubleshooting Problem Possible Cause Solution The transmit light Faulty AC adapter Check the power outlet and does not go on after or faulty power outlet the AC adapter; if possible, DC power is applied check for correct voltage of to the transmitter the AC adapter. -
Page 11: Technical Specifications
User and Installation Guide Technical Specifications Transmitter: Audio transmission method: Digital, uncompressed Transmitter frequency: 2.4 GHz Transmitted data rate: 5 Mbps Transmitter operating range: max. 200 ft. line of sight, max. 50 ft. through walls and ceilings Audio sampling method: 128 times oversampling Receiver: Output level: 1 Vrms Frequency response: 2 Hz …... -
Page 12: Volume Control
User and Installation Guide IMPORTANT SAFETY INFORMATION ATTENTION! READ THESE SAFETY INSTRUCTIONS CAREFULLY AND HEED ALL WARNINGS IN THIS MANUAL. POWER SOURCE To avoid product malfunction, and to protect against electric shock, fire or personal injury, please observe the following: •... -
Page 13: Important Note
Copyright (C) 2011 Amphony. All rights reserved. The information contained herein is subject to change without notice. Revisions may be issued to advise of such changes and/or additions. All product names, trade names, or corporate names mentioned in this document are acknowledged to be the proprietary property of the registered owners. -
Page 14: Non-Use Periods
• Do not attempt to service the unit yourself. If liquid or any metal objects such as paper clips, wire or staples accidentally fall inside, disconnect the product from the power source immediately, and consult an authorized service center. • Please refer any service to an authorized Amphony service center. Page 1... - Page 15 Copyright (C) 2011 Amphony. All rights reserved. The information contained herein is subject to change without notice. Revisions may be issued to advise of such changes and/or additions. All product names, trade names, or corporate names mentioned in this document are acknowledged to be the proprietary property of the registered owners.
-
Page 16: Limited Warranty
This warranty extends only to the original user of the equipment (“you”, ”your”) and is limited to the purchase price of each part. Amphony and its affiliated companies (”we”, ”our”, ”us”) warrant this Wireless Transmitter / Amplifier Set against defects in materials or workmanship as follows. - Page 17 Note: No responsibility is assumed for the presence of interference outside of Amphony’s control, such as other transmitters or cordless phones, which may hamper proper signal reception. Page 1...
