BMW APIX PAS TDM
BMW APIX PAS TDM
MANUAL
MANUAL
- MODEL : BMW-APIX-PAS-TDM
- DATE : 2018.12.29

Advertisement

loading
Need help?

Need help?

Do you have a question about the BMW-APIX-PAS-TDM and is the answer not in the manual?

Questions and answers

Related Manuals for BMW BMW-APIX-PAS-TDM

Summary of Contents for BMW BMW-APIX-PAS-TDM

  • Page 1 BMW APIX PAS TDM BMW APIX PAS TDM MANUAL MANUAL - MODEL : BMW-APIX-PAS-TDM - DATE : 2018.12.29...
  • Page 2 Index Index 1. Main Spec 2. Block Diagram 3. Dimension 4. External Appearance 5. Connector Pin Assignment 6. Product Composition 7. DIP S/W Setting 8. I-Drive Control 9. OSD(On Screen Display) Control 10. Install 11. Q&A...
  • Page 3 1. Main Spec. 1. Main Spec. 1. Input Spec. (MULTI VIDEO INTERFACE) - 1 x Digital RGB Input (Navigation System source) - 1 x Analog RGB Input (Navigation System source) - 2 x A/V Input (External video source). - 1 x CVBS(REAR CAMERA) Input. (Rear camera source) - 1 x CVBS(FRONT CAMERA) Input.

  • Page 4: Block Diagram

    2. Block Diagram 2. Block Diagram INTERFACE COMMAND EEPROM SYSTEM RECEIVER LVDS LVDS TFT-LCD LVDS LVDS RELAY DIGITAL RGB LVDS Scaler (PIP) RGB+Sync CVBS1 CVBS2 COMPOSITE FRONT CAMERA REAR CAMERA REAR CAMERA POWER...
  • Page 5 3. Dimension 3. Dimension 166mm * 103mm * 22mm 166mm 22mm 103mm * 상기 제품의 외형은 제품 사양에 따라서 변경될 수 있습니다.

  • Page 6: External Appearance

    4. External Appearance 4. External Appearance IMAGE DIP S/W LCD-OUT PROGRAM LCD-IN Digital POWER/CAN NAVI R-TOUCH C-TOUCH...
  • Page 7 4. External Appearance 4. External Appearance LCD-OUT DIP S/W IMAGE LCD-IN PROGRAM Digital POWER/CAN NAVI R-TOUCH C-TOUCH...

  • Page 8: Connector Pin Assignment

    5. Connector Pin Assignment 5. Connector Pin Assignment *NAVI Connect *Touch Connect *POWER Connect ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ① ② ③ ④ ① R DATA (Red) ① Y- 1. Battery (Yellow) 9. N.C ② G DATA (Green) ②...

  • Page 9: Product Composition

    6. Product Composition 6. Product Composition Interface 1 EA A/V Cable(TDM-24pin) 1 EA LVDS Cable 1 EA (Z(6P)-Z(6P) Type R/A) Power Cable 1 EA RGB NAVI(9P) Cable 1 EA...

  • Page 10: Dip S/W Setting

    7. DIP S/W Setting 7. DIP S/W Setting * ON : DOWN , OFF : UP * DIP S/W Example FUNCTION DIP S/W Selection ON : Not Used F15 10.2”, F30 8.8” NAVI OFF : Used ON : Not Used DVB-T(AV1) OFF : Used F20 6.5”...
  • Page 11 8. I 8. I- - DRIVE Control DRIVE Control BMW I-Drive control : Mode Change 6.5” 8.8” Long Press to switch modes, Short press to switch to OEM menu screen. NAVI DVB-T...
  • Page 12 8. I 8. I- - DRIVE Control DRIVE Control BMW I-Drive control : Screen Size Change RearCamera Full size RearCamera middle size 6.5” 8.8” RearCamera None Long Press to Screen Size Change AV Full size AV middle size AV small size...
  • Page 13 8. I 8. I- - DRIVE Control DRIVE Control BMW I-Drive control : DVB-T(DMB) Control - When using DVB-T UI. - When not using DVB-T UI. ① Short press to Selection ④ Short press to channel Up ① Long press to DVB-T UI on ⑤...
  • Page 14 8. I 8. I- - DRIVE Control DRIVE Control BMW I-Drive control : DVD Control - When using DVD UI. ① Short press to Selection ① Long press to DVD UI on ② Move UI Left ② ② ③ Move UI Right ①...
  • Page 15 9. OSD(On Screen Display) 9. OSD(On Screen Display) Control Control I-Drive control : OSD Mode Mode State First Menu Second Menu Third Menu OSD Screen ON for Presss 6 seconds OPTION BACK When OSD screen is displayed, Press short MENU EXIT ENTER Item Selection, Value Selection Item up...
  • Page 16 9. OSD(On Screen Display) 9. OSD(On Screen Display) Control Control OSD Config First Menu Second Menu Third Menu Description DIGTAL-INAVI NAVI-RGB Setting the Connected NAVI Model ELT_DVBT20 DVB-T(DMB) Setting the Connected DVB-T Model ELT_980XU Slim Config Setting the Connected DVD Model DVR-400TA Setting the Connected DVR Model Reset...
  • Page 17 9. OSD(On Screen Display) 9. OSD(On Screen Display) Control Control OSD Option First Third Second Menu Description Menu Menu Original Camera RearCam-Type Equipped with external ExtDevice camera + 12V continuous supply + 12V supply only in Rear RearCam-Power AUTO camera mode + 12V off Detected by P>>>...
  • Page 18 9. OSD(On Screen Display) 9. OSD(On Screen Display) Control Control OSD Option First Third Second Menu Description Menu Menu After RearCam shows FrontCam and returns to FrontCam-RcvOpt previous state Disable feature Use the StreeingWheelButton.. SteeringWheelBtn Disable feature Set button 8 to the mode button.
  • Page 19 9. OSD(On Screen Display) 9. OSD(On Screen Display) Control Control OSD Option First Third Second Menu Description Menu Menu Set up manufacturer of FINE woodworking device for UART Touch use NAVI COM Option Disable feature Reset Execute Option Menu all Reset...
  • Page 20 9. 9. OSD(On Screen Display) OSD(On Screen Display) Control Control OSD Option –> RearCam-Det GEAR : ‘R’ When turned on, enters rear mode ‘R’ Rear mode off when off PDC : Acts like genuine OEM. When the button's green LED is lit, it enters rear mode When the green LED on the button is off WIRE : Without using CAN...
  • Page 21 9. OSD(On Screen Display) 9. OSD(On Screen Display) Control Control OSD Option -> FrontCam-RcvOpt Front Camera Auto Mode 0 second = FrontCam-RcvOpt menu OFF 1~30 second = FrontCam-RcvOpt menu ON & time control NAVI NAVI REAR FRONT AV1(DVB-T) AV1(DVB-T) AV2(DVD) AV2(DVD) Select time of display 1~30 second...
  • Page 22 9. 9. OSD(On Screen Display) OSD(On Screen Display) Control Control OSD Option -> SteeringWheelBtn Long Press to switch modes, Short press to switch to OEM menu screen. Steering wheel button -> on/off selection to OSD MENU OSD Option -> BookMarkBtn Long Press to switch modes, Short press to switch to OEM menu screen.
  • Page 23 9. OSD(On Screen Display) 9. OSD(On Screen Display) Control Control OSD Image NAVI-RGB menu DVD,DVB-T(DMB),NAVI-AV,REAR,FRONT menu First Menu Second Menu Third Menu Action First Menu Second Menu Third Menu Action Brightness Adjust the value of brightness Brightness Adjust the value of brightness Contrast Adjust the value of contrast Contrast...
  • Page 24 9. OSD(On Screen Display) 9. OSD(On Screen Display) Control Control OSD – Screen Menu First Third Second Menu Description Menu Menu Output screen horizontal Horizontal movement Output screen vertical Vertical movement Scale X Up Reduce / increase output screen width Screen Scale X Down Scale Y Up...
  • Page 25 9. OSD(On Screen Display) 9. OSD(On Screen Display) Control Control OSD – Parking Menu First Third Second Menu Description Menu Menu Show parking line Line Display Do not show parking lines Warnings Lang Set warning text language Moving a parking line Horizontal Parking horizontally...
  • Page 26 9. OSD(On Screen Display) 9. OSD(On Screen Display) Control Control OSD Parking – Line Display On / Off Parking Line ON Screen Parking Line OFF Screen...
  • Page 27 9. OSD(On Screen Display) 9. OSD(On Screen Display) Control Control OSD Parking – Change warning language...
  • Page 28 9. OSD(On Screen Display) 9. OSD(On Screen Display) Control Control OSD Parking – Adjust position of parking guide line Possible to adjust the position of parking guide line by Keypad in Horizontal / Vertical menu ※ Pressing this Horizontal / Vertical menu, The OSD screen automatically disappears.
  • Page 29 9. OSD(On Screen Display) 9. OSD(On Screen Display) Control Control OSD – OSD Menu First Third Second Menu Description Menu Menu Horizontal value OSD Menu Horizontal Shift Vertical value OSD menu vertical Shift OSD Menu Display Time (in value Display Time seconds) value Transparency...
  • Page 30 9. 9. OSD(On Screen Display) OSD(On Screen Display) Control Control * IR learning function * In order to work with the IR learning function, a separate IR cable is required. 1. In DVB-T / DVD menu, select User in Sys (OSD list) or User (learned contents).
  • Page 31 Version (Check for future upgrades) Last Source : FDS302KRX-171004 Software Version Software Month Software Year Special Version National : CN=CHINA, KR=KOREA, JP=JAPAN, US=United States Hardware Version PIP model : S3=Sync3, PP=PIP, LV=LVDS Motor model : FD=FORD, BM=BMW, BE=BENZ, MA=MASERATI, LX:LEXUS...
  • Page 32 10. Install Manual 10. Install Manual 1. Installation LVDS/POWER/CAN Connection Screen OEM CABLE(Head Unit) OEM CABLE I-drive...
  • Page 33 10. Install Manual 10. Install Manual 2. Installation Navigation Connection *KD-900 navigation NAVI-IR DVR-IR DVD-IR DVBT-IR SYNC BLUE GREEN NAVI-IR Resistive Touch 16. GND (Black) 15. GND (Black) 14. Mode (Green) 13. Front-Power (Red) 12. Rear-Power (Red) 11. Acc-Power (Red) 10.
  • Page 34 10. Install Manual 10. Install Manual 3. Installation DVB-T(DMB) Remote Control Connection ① or ② NAVI-IR DVR-IR DVD-IR 선택1 DVBT-IR SYNC BLUE ① GREEN GEX-909DTV DVB-T-IR 16. GND (Black) 15. GND (Black) 14. Mode (Green) 13. Front-Power (Red) 12. Rear-Power (Red) 11.
  • Page 35 10. Install Manual 10. Install Manual 4. Installation DVD Remote Control Connection NAVI-IR DVR-IR DVD-IR DVBT-IR SYNC BLUE GREEN DVD-IR 16. GND (Black) 15. GND (Black) 14. Mode (Green) 13. Front-Power (Red) 12. Rear-Power (Red) 11. Acc-Power (Red) 10. N.C 9.
  • Page 36 10. Install Manual 10. Install Manual 5. Installation External Reverse(Rear) Camera Connection : OSD Screen selection WIRE REAR-POWER (Red) 16. GND (Black) 15. GND (Black) 14. Mode (Green) 13. Front-Power (Red) 12. Rear-Power (Red) 11. Acc-Power (Red) 10. N.C 9. N.C 8.
  • Page 37 10. Install Manual 10. Install Manual 6. Installation External Front Camera Connection : OSD Screen selection WIRE 16. GND (Black) FRONT-POWER (Red) 15. GND (Black) 14. Mode (Green) 13. Front-Power (Red) 12. Rear-Power (Red) 11. Acc-Power (Red) 10. N.C 9. N.C 8.
  • Page 38 10. Install Manual 10. Install Manual – – 8.8” 8.8” ② ① Disassemble the bottom cover Disassemble the bottom cover ③ ④...
  • Page 39 10. Install Manual 10. Install Manual – – 8.8” 8.8” ⑥ ⑤ Disassemble OEM Power Cable ⑦ ⑧ Moving MOST Cable Connect OEM Power Cable and Supplied Power Cable...
  • Page 40 10. Install Manual 10. Install Manual – – 8.8” 8.8” ⑩ ⑨ Connect Power Cable to Command Connect the supplied LVDS cable to the monitor...
  • Page 41 10. Install Manual 10. Install Manual – – 6.5” 6.5” ② ① Disassemble the bottom cover ③ ④ Disassemble OEM Power Cable...
  • Page 42 10. Install Manual 10. Install Manual – – 6.5” 6.5” ⑥ ⑤ Connect OEM Power Cable and Supplied Power Cable Connect Power Cable to Command ⑦ Connect the supplied LVDS cable to the monitor...
  • Page 43 11. Q & A 11. Q & A 1. Check the LED status first when interface failure.. - If there is no abnormality after the power is applied, the green LED flashes in units of 1 second. - If the red LED flashes for 1 second, there is no. - If the red LED is on continuously, the interface itself is bad.
