King Song KS-X1 MAX User Manual
  1. Manuals
  2. Brands
  3. King Song Manuals
  4. Scooter
  5. KS-X1 MAX
  6. User manual

King Song KS-X1 MAX User Manual

Hide thumbs

Advertisement

Table of Contents

KS-X1 MAX
User
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KS-X1 MAX and is the answer not in the manual?

Questions and answers

Related Manuals for King Song KS-X1 MAX

Summary of Contents for King Song KS-X1 MAX

  • Page 1 KS-X1 MAX User Manual...
  • Page 3 Cautions Electric scooter is a recreational personal transporter. Before mastering riding skills, you need to do practice. You will be responsible for any injuries or damage caused by a rider’s inexperience or failure to follow the instructions in this manual. Please understand that you can reduce the risk by following all the instructions or warnings in this manual, but you cannot eliminate all the risks.
  • Page 4 Rainy, Snowfield, Grassland, Miriness, Fog, Smoke and so on. Please do not use the other chargers to charge E-scooter, Only use King Song supplied charger. Please do not charge E-scooter, if the charger or power outlet is wet.

  • Page 5: Table Of Contents

    Contents 1. Product Details--------------------------------------------------------01 2. Features ----------------------------------------------------------------04 3. Button Usage ----------------------------------------------------------05 4. Assembly and Set-up------------------------------------------------06 5. APP Usage ------------------------------------------------------------07 6. Folding and Carrying-------------------------------------------------17 7. Adjust the handlebar------------------------------------------------18 8. Battery ------------------------------------------------------------------19 9. Clean and Maintenance-------------------------------------------20 10. Warranty--------------------------------------------------------------21...

  • Page 6: Product Details

    1. The Device & Accessories 1.1 Diagram: KS-X1 MAX Accessories ----------------------------------------------------------------------------------- Screws Hex Wrench Valve Stem Extension Charging Adapter...
  • Page 7 1.2 Functions...
  • Page 8 1.3 Specifications KS-X1 MAX Model No 10 inch Inflatable Tyre Size 40 km/h Top Speed Around 60km Mileage Around 20° Gradeability 48V, 13.5Ah Battery Capacity -10℃/+80℃; 0-90% Humidity Running Condition -10℃/+50℃; 0-90% Humidity Storage Condition 125kg Max Load Input: 100-240V; Output: 54.6V/2A Charger Around 8hrs.

  • Page 9: Features

    Parking Mode Kick-stand Cruise Control System control Reminder Mechanical Bell Accelerator Throttle Button Brake Front Drum Brake + EABS Display Battery Display 5 Bars in monitor Dimension(Unfold) 1167*472*1203mm Dimension(Folded) 1167*472*534mm Net Weight 18kg User Manual*1, Certificate*1, Charger*1, Packing List(pcs) Screws *6, Hex Wrench*1, Valve Stem Exten- sion*1 2.

  • Page 10: Button Usage

    • Digital Speedometer Display, Easy to Read Speed. • Real-time 5 Bars Battery Display. • 1~3 Speed Gear, Press Button to Switch. • Malfunction Display. 3. Button Usage • Power ON/OFF: Long press the button for 3 seconds, all icons are lighting, showing speed & battery. km/h km/h •...

  • Page 11: Assembly And Set

    • Click the button for two times to change the speed gear from 1 to 3 levels, LED display ECO / D / S. Max speed is increasing when LED display from ECO to S. km/h km/h km/h 4. Assembly and Set-up 1.

  • Page 12: App Usage

    3. Install six screws (two on 4. Verify that your Scooter can each side) with the included be powered on and off. hex wrench. 5. APP Usage 5.1 First Ride Mobile device Requirement: iOS 10.0 or above, Bluetooth 4.0 or above. Install the APP and register/login.
  • Page 13 APP, to ensure the APP can run normally in your mobile device. Open Bluetooth/location (or GPS), Click ‘Search’ - -> Click the corresponding model KS-X1 MAX in device list to connect. The E-scooter will beep when APP is connected with E-scooter.
  • Page 14 • Step 2: Wear protective equipment. • Step 3: Try to slide with one • Step 4: Touch the throttle leg. slightly and try to put two leg on the deck.
  • Page 15 • Step 5: During riding, try to • Step 6: Try to use the release the throttle and pull headlight. the brake lever. 5.3 Warnings • Wear protective equipment. • Do not ride in rainy or cross puddles.
  • Page 16 • Do not load over 125kg. • Ride slowly in special cases. • Do not place one foot on the • Do not tread the back of the deck or on the ground when fender. riding.
  • Page 17 • Do not leave your hands • Do not ride upstairs or during riding. downstairs, or over obstacles. • Do not hold a child during • Do not ride on highway or riding. motor vehicle road.
  • Page 18 • Do not ride with sharp turn. 5.4 Firmware Upgrade Please enter APP and enter Mine Video Data Study, and find how to upgrade firmware via User APP. 5.5 Cruise Control Open cruise-control in APP, while you keep the same speed, riding for 3~5 seconds, the E-scooter will be in cruise-control mode(running at constant speed on flat road) Please use cruise-control only on flat road, or you will fall down on other...
  • Page 19 5.6 Error Description Display Defect Description Solutions Wrong in 1. Check whether the display communication control board is well connected; 2. Replace the display. 3. Replace the control board. Encounter obstacles 1. Release the accelerator and that E-scooter can’t get stop braking.
  • Page 20 Low voltage alarm 1. Stop riding and get scooter charged. 2. Restart. 3. Check if firmware has been wrongly upgraded. 4. Replace the control board. High voltage alarm 1. Check whether scooter has been fully charged, riding the scooter at low speed, avoiding braking suddenly when scooter is fully charged.
  • Page 21 2. Check whether the motor wire is damaged, and whether the temperature signal wire of the motor wire is short-circuited to the ground. 3. Replace the motor. Control board high 1. Stop riding or riding scooter at temperature low speed, avoiding climbing. 2.

  • Page 22: Folding And Carrying

    Lack of phase, 1. Restart and turn scooter on as mos tube drive failure static, avoiding turning on scooter while advancing. 2. Replace the control board. Lack of series number 1. Check whether the firmware version is correct. 2. Reset the serial number. 6.

  • Page 23: Adjust The Handlebar

    Carrying Hold the handlebar stem with either one hand or both hands to carry. 7. Adjust the handlebar If the handlebar and its stem sway during riding, use the hexagon wrench to tighten the screws on the folding mecha- nism.

  • Page 24: Battery

    8. Battery 8.1 Temperature Effect on Battery Battery power will vary with the temperature, mileage per charge will have slight difference under different temperature, and following table is just for your reference. Temperature(℃) 174Wh using ratio 100% 105% 110% MPC(Km) MPC: Mileage per fully charged.

  • Page 25: Clean And Maintenance

    9. Clean and Maintenance 9.1 Clean and Maintenance When charging • Please place the E-scooter in cool and ventilate places to release heat. • Please avoid high temperature or moist. • Please avoid water into the E-scooter to prevent electric shock, especially water drops from the charger cable to the the charging port.

  • Page 26: Warranty

    If the voltage is not in this range, please contact the distributor for battery pack maintenance. Please charge the E-scooter at least one time each month, to extend the battery pack lift time. Please do not disassemble, assemble or change the battery by yourself.
  • Page 27 10.2 Exclusion from Warranty Above limited warranty DOES not include damage or lose not caused item’s defectives (i.e. warranty only covers manufacturer defectives, does not cover any damage, unauthorized modification, improper operation, disassembly etc.) 10.3 After Sale Service Please contact the local sellers or distributors for after-sale service.
  • Page 28 Kingsong Intell Co.,LTD Address : BLDG 7, NO 71 XINGHU RD, 8TH INDUSTRY PARK, HONGXING, YUTANG,GUANGMING,SHENZHEN Tel : +86-755-23193477 Fax : +86-755-23193248 E-mail : info@szkingsong.com...
