American Dynamics ADRL3TRK Series Installation Manual
American Dynamics ADRL3TRK Series Installation Manual

American Dynamics ADRL3TRK Series Installation Manual

Speeddome ultra programmable dome on a rail
Hide thumbs Also See for ADRL3TRK Series:

Advertisement

SensorRail
ADRL3TRK Series
SpeedDome
Ultra Programmable
®
Dome on a Rail

Installation Guide

CAUTION: Only a certified installer is
authorized to install this equipment.
Installation by anyone else will void the
SensorRail warranty.
Contents
About this Guide ............................................................ 1
About the Product .......................................................... 1
Before You Begin........................................................... 3
Installation Steps ........................................................... 5
1. Install Threaded Rods ............................................ 5
2. Install PVC Holders ................................................ 6
4. Install Rail Sections................................................ 7
5. Install Anti-Sway Cables ........................................ 8
and Trolley Stop/Retrieval Tool .................................. 9
7. Install Optical Stop Labels.................................... 10
8. Install the PowerRail Module................................ 11
9. Install the Camera Trolley .................................... 12
10. Attach Light Reducing Sections ........................... 13
11. Clean the Rail ...................................................... 13
12. Check Electrical Connections .............................. 13
13. Configure the System .......................................... 14
14. Install the Cowling................................................ 15
15. Install End Covers................................................ 16
Ordering Parts ............................................................. 17
Specifications .............................................................. 20
Declarations................................................................. 21
© 2006 Sensormatic Electronics Corporation
SENSORRAIL IIIE ADRL3TRK SERIES
INSTALLATION GUIDE
IIIE

About this Guide

This guide explains how to install the SensorRail
IIIE system. It does not explain how to:
• Determine the exact mounting location of the
rail. This is determined by the customer's needs
and the site's ceiling structure.
• Program or operate the system. See SensorRail
IIIE User Guide 8200-0593-04 and SpeedDome
Ultra and AD Matrix User Guides.
• Service the system. See Service Guide
8200-0593-03.
If you need assistance...
Contact your certified support representative.

About the Product

The SensorRail IIIE system enables a SpeedDome
Ultra dome camera to transmit video as it moves
along a rail to the ideal surveillance position.
The system consists of:
• 2.5m (8.2ft) rail sections (number determined by the
total length of the rail) with installation hardware
• A light-reducing section at each end of the rail
• Ceiling suspension assembly, which includes M8
threaded rods, ceiling attachment hardware (not
supplied), and mounting stirrups
• Copper tracks
• Camera trolley equipped with dome camera, RF
transmit antenna, and motor
• PowerRail module that supplies dc power to the
camera trolley, converts RS-422 data to RS-232 data
used by the trolley, and receives the video signal
from the dome camera
• Trolley stop and retrieval tool
RF receive antenna.
IMPORTANT! At least two people are required to
install this product safely and efficiently. Follow all
procedures described in this guide explicitly. If
installation difficulties occur, call:
American Dynamics Technical Services
Toll Free 800-507-6268, Option 2
International: 561-912-6259, Option 2
In Europe:
Technical Services at EMEA AD Technical Support
+800 CALL TYCO or (+800 22 55 8926)
From the UK: 08701 238 787
Direct: +31 475 352 722
1 of 34
8200-0593-02, REV. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADRL3TRK Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for American Dynamics ADRL3TRK Series

  • Page 1: Table Of Contents

    Appendix A: RF link DIP switch settings ... 32 Appendix B: Alternate RF antenna location ... 32 Appendix C: AD SensorRail Control Utility... 33 © 2006 Sensormatic Electronics Corporation SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE About this Guide This guide explains how to install the SensorRail IIIE system.
  • Page 2: Product Features

    Vision area (for surveillance), dead zones (for stopping), and maintenance areas (for servicing) Rail Vision Area Vision Area + Two 1.5m (5ft) Dead Zones +Two 30cm (1ft) Light Reduction Sections = Total Length of Rail SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE M8 Threaded Rod Jointing Plate...
  • Page 3: Before You Begin

    A Hilti MF C31/8 fast grip system and Hilti MQ-41 suspension bar (not supplied) may be required to attach the rail to ceiling red iron. SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE Acoustic Tile Ceilings WARNING! DO NOT mount the rail structure directly to an acoustic tile ceiling;...
  • Page 4: Parts Supplied

    - Steering wheel to retrieve copper tracks for servicing. Note: The tool used to install copper tracks is not supplied with the system. SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE Parts to be Purchased Separately • M8 threaded rods and related hardware, and ceiling connection assemblies •...
  • Page 5: Installation Steps

    Wear protective eyewear when using a laser leveling device. Refer to the device manufacturer’s instructions for additional safety precautions. SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE 1. Install Threaded Rods Threaded rods secure the rail system to the ceiling. Each rod attaches to the ceiling using one of the...
  • Page 6: Install Pvc Holders

    Note: The other half of the holder will remain outside the rail. This half will insert into the next rail section. SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE 3. Install Stirrups, Eyebolts, and Jointing Plates • A stirrup is required to mount each section to the threaded rod above.
  • Page 7: Install Rail Sections

    3. Secure each rail section to the rod using a Nylon stop nut. DO NOT tighten the nut. SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE C. Level the rail sections. 1. Level sections by adjusting the two center screws in the top jointing plates.
  • Page 8: Install Anti-Sway Cables

    • U-bolt clamps, wire thimbles for 1/8-inch cable • 9.6mm (3/8in) diameter jaw & jaw turnbuckles; 544kg (1200 lbs) break strength, 362kg (800 lbs) working load limit. SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE Procedure At the ceiling: A. Install I-beam clamps on the side of the beam opposite the cable pull direction.
  • Page 9: Insert Copper Tracks And Trolley Stop/Retrieval Tool

    3. Tighten the screw to secure the tape. 4. Insert the service block with the tape attached. Ensure the tape faces the start end of the rail. SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE C. Insert the service trolley “handle first” into the rail.
  • Page 10: Install Optical Stop Labels

    J. At the end of the rail, bend the excess copper track over the PVC holder. K. Remove the copper track installation/ retrieval tool from the rail. SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE 7. Install Optical Stop Labels Optical stop labels affix inside the rail nearest the PVC holder to enable the trolley to recognize the beginning and end of its route.
  • Page 11: Install The Powerrail Module

    (RS-232 data) wires to the module and crimp their other end to the rail. Ensure wires are long enough to reach the copper tracks without stretching. SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE D. Connect RS-422 data from the video controller to the module.
  • Page 12: Install The Camera Trolley

    Ensure wires are not caught in the latching mechanism before locking the dome in place. SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE B. Remove the service block at the start end of the rail holding the tape in place and slide the camera trolley onto the rail.
  • Page 13: Attach Light Reducing Sections

    B. Repeat step A to attach the other light reducing section to the end of the rail. SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE 11. Clean the Rail The rail is sensitive to fingerprints. To clean the rail, use a tissue soaked with window glass cleaner or use a window glass cleaning pad.
  • Page 14: Configure The System

    - Privacy zones - Direction indicators - Freeze frame - Home position. SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE On your laptop computer, use the AD SensorRail Control configurator screen (shown above) to test the trolley and dome camera functions. Also, check the entire rail for joint alignment.
  • Page 15: Install The Cowling

    Yellow LED: TX Rail Trolley CPU Board 12. Note all failures. SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE 14. Install the Cowling Mirrored cowling is used to conceal the location of the camera trolley. Grooves in the lower part of the rail are used to secure the cowling.
  • Page 16: Install End Covers

    • End covers (2) • Cover screws (8). Install an end cover to each end of the rail using four Phillips-head screws each. INSTALLATION IS COMPLETE. SENSORRAIL IIIE ADRL3TRK SERIES 8200-0593-02, REV. A 16 of 34 INSTALLATION GUIDE...
  • Page 17: Ordering Parts

    SensorRail III, PowerRail, RF receiver 2,4GHz, PAL ADRL3PWRANTP SensorRail III, PowerRail, RF receiver antenna 2,4GHz, PAL ADRL3PWRR58P SensorRail III, PowerRail, RF receiver 5,8GHz, PAL ADRL3PWRA58P SensorRail III, RF antenna receiver 5,8GHz, PAL SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE 17 of 34 8200-0593-02, REV. A...
  • Page 18 ADRL3CUI95U SensorRail III, copper tracks 95m (311,68ft), 4 rolls of 95m, universal ADRL3CUI100U SensorRail III, copper tracks 100m (328,08ft),4 rolls of 100m, universal ADRLCIT SR3 copper install tool SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE 18 of 34 8200-0593-02, REV. A...
  • Page 19 SensorRail III, mirrored cowling 90m (295,28ft), universal ADRL3BUL95U SensorRail III, mirrored cowling 95m (311,68ft), universal ADRL3BUL100U SensorRail III, mirrored cowling 100m (328,08ft), universal ADRL3BUL3.5U 3.5 meters mirror cowling to add when using SR3-END-COVER SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE 19 of 34 8200-0593-02, REV. A...
  • Page 20: Specifications

    RS-422 data ... Cat. 5. 1 x twisted pair, shielded * KX-6 for <300m from PowerRail to matrix switcher, KX-8 for <800m from PowerRail to matrix switcher. SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE Environmental Operating temperature ... –10 to 50°C Storage temperature ...
  • Page 21: Declarations

    Safety ...EN 60950 EN 50371 Declarations Thank you for using American Dynamics products. We support our products through an extensive and worldwide network of dealers. The dealer, through whom you originally purchased this product, is your point of contact if you have a need for service or support.
  • Page 22 50cm 10cm 30cm 1.25m 90cm PVC Holder Rail Section SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE 2.5m 2.5m 22 of 34 2.5m M8 Rod 5cm (2in) 8200-0593-02, REV. A...
  • Page 23 3, 4, 5, 6… SENSORRAIL IIIE ADRL3TRK SERIES 8200-0593-02, REV. A 23 of 34 INSTALLATION GUIDE...
  • Page 24 SIDE VIEW TOP VIEW Eyelet location Right Way for Maximum Cable Strength SENSORRAIL IIIE ADRL3TRK SERIES 8200-0593-02, REV. A 24 of 34 INSTALLATION GUIDE...
  • Page 25 Screws (6) SENSORRAIL IIIE ADRL3TRK SERIES 8200-0593-02, REV. A 25 of 34 INSTALLATION GUIDE...
  • Page 26 SENSORRAIL IIIE ADRL3TRK SERIES 8200-0593-02, REV. A 26 of 34 INSTALLATION GUIDE...
  • Page 27 PowerRail 27Vdc Ground Track 1 2 3 4 PowerRail Track SENSORRAIL IIIE ADRL3TRK SERIES 8200-0593-02, REV. A 27 of 34 INSTALLATION GUIDE...
  • Page 28 15cm SENSORRAIL IIIE ADRL3TRK SERIES 8200-0593-02, REV. A 28 of 34 INSTALLATION GUIDE...
  • Page 29 SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE 29 of 34 8200-0593-02, REV. A...
  • Page 30 DB25 Female (PowerRail side) SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE DB9 Female (PC side) Conv PC 30 of 34 PowerRail To PC 8200-0593-02, REV. A...
  • Page 31 Plastic Card Cowling Mirrored (external) Side SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE Direction of Ply 31 of 34 8200-0593-02, REV. A...
  • Page 32: Appendix A: Rf Link Dip Switch Settings

    DIP Switch Channel Channel 1 (2414.5MHz) Channel 2 (2428.5MHz) Channel 3 (2442.5MHz) Channel 4 (2456.5MHz) Channel 5 (2470.5MHz) Appendix B: Alternate RF antenna location Use Install Kit ADRL3RXBRK. SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE 32 of 34 8200-0593-02, REV. A...
  • Page 33: Appendix C: Ad Sensorrail Control Utility

    VIEW. To store a view, click SET, enter the number, and then click VIEW. The latest software supports 16 views. SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE Pattern (also known as Tour). To run a stored pattern, enter the pattern number (1-3) using the numeric keypad and then click PATTERN.
  • Page 34 PC Functions Com1/2. Click the appropriate radio button to select the serial communications port for the computer. SENSORRAIL IIIE ADRL3TRK SERIES INSTALLATION GUIDE Camera Monitor Functions Camera monitor functions (highlighted areas change) Menu. Click MENU to command the dome to enter the camera monitor’s on-screen menu mode, as well as...
