Specifications

Camera
Wide Camera Sensor
Scanning Mode
Lens
EFL(mm)
FOV (degree)
Lens Structure
Image Circle
Optical Distortion
Relative Illumination
Chief Ray Angle
TVL
Focus range
Tele Camera Sensor
Scanning Mode
Lens
EFL(mm)
FOV (degree)
Lens Structure
Image Circle
Optical Distortion
Relative Illumination
Chief Ray Angle
TVL
Focus range
Processor
ASIC
VPU
Memory
PMIC
Audio Codec
Sensors
Humidity/Temperature
sensor
Light level sensor
Environment color
Temperature sensor
PIR sensor
Sony IMX317 1/2.5", 3840x2160 (1.62um), D=7.14, CRA = 4.5° WDR
Progressive
Fix iris/focus 1/2.5" F2.0± 5%
3.16± 5% mm
FOV-D = 146.6° ± 5°
FOV-H = 123.1° ± 5°
FOV-V = 65.1° ± 5°
2G3P
Max ø7.28mm
-66.3% @ D=7.14mm
35% @ D=7.14mm
16.1° @ D=7.14mm
Center : 1450TVL Focus &Test at 5M
0.7F : 1100TVL Focus &Test at 5M
2m~6.5m (face must be no smaller than 80x80 pixel)
Sony IMX317 1/2.5", 3840x2160 (1.62um), D=7.14, CRA = 4.5° WDR
Progressive
Fix iris/focus 1/2.3" F2.0± 5%
7.35± 5%mm
FOV-D = 58.4° ± 5°
FOV-H = 50.2° ± 5°
FOV-V = 27.5° ± 5°
2G3P
Max ø7.5mm
-13.69% @ D=7.2mm
40% @ D=7.2mm
15.9° @ D=7.2mm
Center : 1450TVL Focus &Test at 9M
0.7F : 1100TVL Focus &Test at 9M
6.4m~10m (face must be no smaller than 80x80 pixel)
NT96685(Novatek), build in 4Gb DDR
MA2485(Intel), build in 4Gb DDR
SPI NAND Flash 4Gb
PMIC
Audio Codec (Build in 2ch EQ,DRC for internal Mic, bypass for
external plug-in)
Temperature : Measurement Range :-10~60°C
Accuracy : 5~60°C: ±3°C (At 1m/s air flow)
-10~5°C: ±3°C (At 1m/s air flow)
Humidity: Measurement Range :0~99%RH
Accuracy:20~80%RH: ±5%RH
Measurement Range :0~20K Lux
D65 => 6500K+/-500K
TL84 => 4100+/-500K
IncA => 2856K+/-500K
Horizon => 2300K+-500K
Color temperature sensor:2000~10000k Accuracy:±20 %
Detection Range : 2 Meter(H=100° ±10° / V=60° )
Sensitivity level: L / M / H
30
Other RH: ±7%RH
Accuracy:±10%
