7.4 System Settings

To access the Settings screen touch the Gear Icon. The System can be upgraded, the time
display changed from 12-hour to 24-hour, and Time and Date can be entered or changed, as
shown in Figure 20. Touch window to change settings then touch the SET button to lock in the
figure. A pop-up window opens, confirming Time or Date resets. To return to Resources Screen
touch the back arrow button at the top left corner of the screen.
Touch window
to change

7.5 Technical Support

To access the Technical Support screen touch the Tech Support button on the Resources
screen. SPEX contact information for the USA Headquarters and Europe Sales Office is listed on
this screen (Figure 21). To return to Resources screen touch the back arrow button at the top
left corner of the screen.
1300-87052-1A, REV 1
Figure 20 – Settings Screen
Figure 21 – Tech Support Screen
SPEX SamplePrep LLC
6875D Freezer/Mill
Note: System Update button
appears only when an
external flash drive is
connected to the USB Port
(back of controller).
[System updates furnished
only by SPEX, if necessary]
To update system, connect
SPEX flash drive. After unit
detects device, touch button
to upgrade system.
Remove flash drive when
upgrade is complete.
