Disco Speaker with Microphone BT-X53
The manufacturer Technaxx Deutschland GmbH & Co.KG hereby
declares that this device, to which this user manual belongs, complies
with the essential requirements of the standards referred to the Directive
RED 2014/53/EU. The Declaration of Conformity you find here:
www.technaxx.de/ (in bar at the bottom "Konformitätserklärung").
Before using the device the first time, read the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute
from German fixed-line and 42 cent/minute from mobile networks).
This device has a rechargeable battery. It must be fully charged
before first use. NOTE: Charge the battery of the device every 2–3
Keep this user manual for future reference or product sharing carefully.
Do the same with the original accessories for this product. In case of
warranty, please contact the dealer or the store where you bought this
product.
Enjoy your product. *Share your experience and opinion on one of
Features
• LED lighted front panel with sound recognition
• Rotating disco light on the top
• Bluetooth, Micro SD, USB, AUX-IN and FM-Radio functions
• 30W loudspeaker
• Inclusive one microphone for singing
• 2 microphone plugs for duets
• Built-in 4000mAh battery
®
MusicMan
Free Email: support@technaxx.de
month if it is not used!
the well-known internet portals.
* User Manual
Warranty 2 years

Advertisement

loading
Need help?

Need help?

Do you have a question about the BT-X53 and is the answer not in the manual?

Questions and answers

Summary of Contents for MusicMan BT-X53

  • Page 1 ® MusicMan * User Manual Disco Speaker with Microphone BT-X53 The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares that this device, to which this user manual belongs, complies with the essential requirements of the standards referred to the Directive RED 2014/53/EU.
  • Page 2: Technical Specifications

    DC 5V / 1.2A Operating temperature 0°C up to +40°C Material PC / ABS / Wood 3.0Kg / (L)22.9 x (W)21.8 x Weight / dimension (H)34.2cm MusicMan® BT-X53, wired Package content microphone, AUX cable, Micro- USB charging cable, user manual...
  • Page 3: Product Details

    Product details Disco light Forward / next Power LED speaker grid Modes LED indicator Line in Echo microphone Microphone plug 1 Light button Microphone plug 2 Mode button Line out Repeat / back Micro-SD card slot Handle USB port Volume +/- FM-antenna Play / pause DC in 5V/1.2A (Micro USB)
  • Page 4 The working indicator LED turns blue. Now the device is ready for pairing. Open the Bluetooth settings on your Bluetooth device and select the „MusicMan BT-X53“ from the device list. You can also use the speaker with Aux-In, USB stick, or Micro- SD card.
  • Page 5 If the pairing is successful, you will hear a connection sound and the speaker enters idle state. Auto reconnection When the BT-X53 is in off state, switch it on and it will reconnect automatically to the last connected device if it is reachable. Micro-SD card mode Insert a Micro-SD card in the device in on state.
  • Page 6: Troubleshooting

    Troubleshooting If the BT-X53 fails to link to your mobile device or if it fails to play music after being connected, the user shall check if your mobile device supports A2DP. If you cannot connect the BT-X53 to your...
  • Page 7 ● Do not modify, repair or remove without professional guidance. ● Do not use corrosive or volatile liquid for cleaning. ● Do not drop or shake the BT-X53, it may break internal circuit boards or mechanics. ● Keep the BT-X53 in dry and ventilated environment.
