BT–X3 2.1 Soundstation
The Declaration of Conformity is under the link:
www.technaxx.de/ (in bottom bar "Konformitätserklärung")
Before using, read this user manual carefully.

Features

Bluetooth HiFi 2.1 Surround System with excellent
sound in deep and high sound areas
RMS: 15W + (6W x 2) = 27W
Plays music from SD / SDHC / MMC memory card
and USB flash drive (up to 32GB)
Connection to PC/Notebook, DVD/CD player,
MP3/MP4 player
Connection to all Bluetooth compatible devices
(Mobile Phones, PDA, Tablet, etc.)
AUX-IN via audio jack cable
Clear and simple operation
With the switch on the back (ON/OFF) you can turn

USB or Memory Card

(Formated with Fat32)
Insert an USB or a SD/SDHC/MMC card with MP3
tracks in the
The device starts playing the first track automatically
from inserted slot. The red LED flashes.
MusicMan
on or turn off the device.
or
®
slot.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BT–X3 2.1 Soundstation and is the answer not in the manual?

Questions and answers

Related Manuals for MusicMan BT–X3 2.1 Soundstation

Summary of Contents for MusicMan BT–X3 2.1 Soundstation

  • Page 1 ® MusicMan BT–X3 2.1 Soundstation The Declaration of Conformity is under the link: www.technaxx.de/ (in bottom bar “Konformitätserklärung”) Before using, read this user manual carefully. Features Bluetooth HiFi 2.1 Surround System with excellent sound in deep and high sound areas...

  • Page 2: Bluetooth Mode

    Press to select next or for previous track. Play music: Press button to start the music. Pause music: Press button while music is playing to switch between pause and continue playing. The red LED lights up permanently. Stop music: Press button while music is playing to stop the music (Pause = Stop).
  • Page 3 4) With a sound “Ding Dong” you had successfully connected with Bluetooth. The RED light stops flashing, it is just on light. Then you can play music on the device. 5) To exit the Bluetooth mode of the device, simply disconnect the Bluetooth connection from your mobile phone.
  • Page 4 Upper view USB Jack USB slot SD / SDHC / MMC Memory card slot Jack PREV Preview music title Play / Pause / Play music / Pause music / Mode Mode button NEXT Next music title Switch between SD card – USB – MODE Bluetooth (AUDIO INPUT) Attention:...
  • Page 5 Side Volume Treble Bass...

  • Page 6: Technical Specifications

    Technical specifications 5” + (2.5” x 2) equals Speakers 15W + (6W x 2) = 27W Impedance 4Ω Bass / 4Ω Satellites S/N Ratio 60 dB Frequency 25Hz ~ 20KHz Dimensions Subwoofer 20 x 19 x 23,5cm Weight Subwoofer 2,85 kg Dimensions Satellites 9 x 9 x 9cm Weight Satellites...
