Toto SW3056AT40 Instruction Manual page 11

Basic Operations
Operate the controls on the remote control; a beep sounds when the main unit
receives the signal.
The ush buttons
The type of button
varies depending on the
type of toilet bowl or
tank.
Full ush/
Light ush
Full ush
Toilet ush button
not included
● Functions that operate
when a button is
pressed during "Rear
cleansing", "Rear soft
cleansing", "Front
cleansing" or "Wide
front cleansing".
Note
● Sitting back on the
toilet seat makes it
easier to adjust the
wand position and
to reduce splashing.
"Oscillating cleansing"
The wand moves back
and forth to cleanse
your rear thoroughly.
The setting changes
between "ON" and
"OFF" each time the
button is pressed.
"Pulsating cleansing"
Cleanses with the water
pressure pulsating
between soft and strong.
"Wand CLEAN"
The setting changes
between "ON" and
Cleans the wand with EWATER+
"OFF" each time the
The wand can be automatically cleaned when you use the cleansing
button is pressed.
functions (Rear cleansing , Front cleansing, etc.). (Page 24)
20
Flushing *
1
"Full ush"
Performs a full ush.
"Light ush"
Performs a light ush.
Opening and closing * 2
"Opening and closing the toilet seat"
Opens and closes the toilet seat.
Stopping
"Stopping"
Stops the operation.
Cleansing
"Rear cleansing"
Cleanses your rear.
"Rear soft cleansing"
Cleanses your rear with soft
embracing water ow.
The setting changes between and each time
the is pressed.
"Front cleansing"
Serves as a bidet for ladies.
"Wide front cleansing"
Gently cleanses a wide area.
The setting changes between and each time
the is pressed.
Drying
"Warm air drying"
Dries your rear.
● The "Water pressure adjustment", "Wand
position adjustment" and "Personal setting
lock" functions are swipe operated.
*3
"Personal setting lock"
You can store your preferred "Water
pressure", "Wand position" and "Warm
water temperature" settings.
To store a settings Page 60
●
● To use
To use To use
(Swipe left) (Swipe right)
Select or and press the button for the
cleansing you want to use.
The "Wand position" and "Water pressure" lamps will
light up for about 10 seconds in their set positions,
and the "Water temperature" display switches.
*1 Available only when "FLUSH" button is located on the top side of the remote control.
*2 Except SW3046AT40, SW3046, SW3044AT40, SW3044
*3 Remote control transmitter (Front side, Top side)
● Functions that operate when a button is pressed
during "Rear cleansing", "Rear soft cleansing",
"Front cleansing" or "Wide front cleansing".
Note
● Sitting back on the toilet seat makes it easier to
adjust the wand position and to reduce splashing.
"Water pressure adjustment"
You can select from 5 levels of water pressure.
The setting changes by one level whenever you
swipe to the left or right.
[-] Softer
[+] Stronger
After you swipe to change the "Water pressure adjustment"
setting, the set position will light for 10 seconds.
It will return to the 3rd position for a while (not
exceeding a maximum of 5 minutes) once operation
of the remote control has finished.
"Wand position adjustment"
You can select from 5 levels of wand position between
the front and the rear, using the [ ] and [ ] buttons.
The setting changes by one level whenever you swipe to the left or right.
[ ] Moves to the front
[ ] Moves to the rear
After you swipe to change the "Wand position adjustment"
setting, the set position will light for 10 seconds.
It will return to the 3rd position for a while (not
exceeding a maximum of 5 minutes) once operation
of the remote control has finished.
21
