Toto SW3056AT40 Instruction Manual page 10

Preparation
1. Insert the battery
1
Remove the remote control
from the hanger.
Remote
control
Hanger
2
Open the battery cover and
insert two AA batteries.
Close
Open
Battery
cover
● When batteries are properly inserted,
temperature levels appear on the display of
the remote control (back side).
➞ When the temperature levels are not
displayed, perform step 3 of "Language
Settings" in page 56.
● The display goes out when no button on
the remote control is pressed for about 60
seconds or more.
3
Mount the remote control in
the hanger.
■ About the batteries
Use dry cell, alkaline batteries.
Be sure to follow "Safety Precautions" to prevent
the batteries from rupturing or leaking uid, etc.
(Pages 7, 8)
18
Using the Product for the First Time
If the remote control is secured
(for anti theft)
1
Remove the screw from the
remote control xture.
(View from side)
Remote
control
Hanger
Screw
Remove
Phillips screwdriver
2
Remove the remote control
from the hanger.
■ To secure the remote control again
Tighten and x the screw.
(Overtightening may cause damage to parts
such as the hanger.)
2. Turn on the power
1
Insert the power plug.
The wand extends and then retracts.
2
Check that the "Power" LED
lights up.
When it is off, switch the "Power" to "ON".
To operate from the back of remote control
Press "Power ON/OFF" button about 3
Wall
seconds or longer.
To operate from the front of remote control
* Recommended if the remote control is
secured to prevent theft.
Press "Oscillating cleansing" button
about 10 seconds or longer.
<Power>
To turn the power "OFF"
Perform the same operation as step
above
The "Power" LED goes off.
3. Open the shutoff valve
1
Fully open the shutoff valve.
Shutoff
valve
2
19
