T
801
TRANSFORMER DETAILS
CRT CIRCUIT
VOLTAGE READINGS were obtained under the fo llo w in g conditions:
INTENSITY
..............................................
Counterclockwise
Voltage readings marked with asterisk f* f were obtained w ith the
control set for normal operation
Also see IMPORTANT note on Time Base Trigger D iagram
