Introduction
The Type 543B Oscilloscope is o versatile laboratory
instrument designed tor use with all Tektronix lettered- or
1-series plug-in units.
VERTICAL DEFLECTION SYSTEM
Refer to Table 1-1 for the characteristics.
SWEEP GENERATOR
Sweep Rates 0.1 /isec/cm to 5 sec/cm in 24 calibrated
steps. Displayed sweep-rate accuracy is
= 3 % . An uncalibrafed variable sweep-
rate control permits the sweep to be
slowed to at least 0.4 of the indicated
rate.
Sweep Any sweep rate can be increased 2, 5, 10,
Magnification 20, 50 or 100 times by expanding the
center portion of the display horizontally.
Sweep-rate accuracy is within — 5% in the
magnified positions until the sweep rate
exceeds 0.02 ,usec/cm.
Plug-In
Unit
Type 1A1*
Type 1A2*
Type B
Type CA*
Type D
Type E
Type G
Type H
Type K
Type L
Type M*
Type N **
Type O **
Type Q " *
Type R**
Type S**
Type Z -*
"M u ltip le -tra c e plu g -in units.
"•S p e c ia l feature p lug -in units. See you r Tektronix catalog for more inform ation on any o f these plug-in units.
SECTION 1
CHARACTERISTICS
TABLE 1-1
Plug-In Characteristics for the Type 543B Oscilloscope
Calibrated
Deflection Factor
50mv/cm to 20 v/cm
dc to 33 me
5 mv/cm
dc to 23 me
50mv/cm to 20 v/cm
dc to 33 me
0.005 v/cm to 20 v/cm
2 cps to 12 me
0.05 v/cm to 20 v/cm dc to 20 me
0.05 v/cm to 20 v/cm dc to 24 me
1 mv/cm to 50 v/cm dc to 300 kc-2 me
50//.v/cm to 10 mv/cm
0.06 cps to 20 kc-
60 kc
0.05 v/cm to 20 v/cm
dc to 20 me
5 mv/cm to 20 v/cm
dc to 15 me
0.05 v/cm to 20 v/cm
dc to 30 me
5 mv/cm to 2 v/cm
3 cps to 24 me
0.05 v/cm to 20 v/cm
dc to 30 me
0.02 v/cm to 10 v/cm
dc to 20 me
10 mv/cm
dc to 600 me
0.05 v/cm to 20 v/cm
dc to 25 me
10 ,nstrain/cm to
dc to 6 kc
10,000 /(Strain/cm
0.5 ma/cm to 100 ma/cm
0.05 v/cm to 0.5 v/cm
0.05 v/cm to 25 v/cm dc to 13 me
Trigger Source Internal, external, and line.
Selection
Trigger Mode
Automatic, dc, ac, and oc low-frequency
Selection rejection.
Trigger Signal
Internal (ac): Minimum deflection is 2 mm,
Requirements from 150 cps to 10 me, rising to 1 cm at
30 me with less than 1 mm of horizontal
jitter at a sweep rate of 20 nsec/cm.
Internal (dc): Minimum deflection is 6 mm
to 10 me.
Internal (ac low-frequency rejection)? Mini­
mum deflection is 2 mm, from 30 kc to
10 me, rising to 1cm at 30 me with less
than 1 mm of horizontal jitter at a sweep
rate of 20 nsec/cm.
Internal (automatic):
150 cps. W ill trigger from 50 cps to 10 me
with increased deflection.
External (ac): Minimum amplitude is 0.2
volt, from 150 cps to 10 me, rising to 1
volt at 30 me with less than 1 mm of hori­
zontal jitter at a sweep rate of 20 nsec/cm.
Minimum Risetime
Bandpass
10.6 nsec
15.2 nsec
10.6 nsec
30 nsec
18 nsec
15 nsec
0.18 ,usec
6 /xsec
18 nsec
23 nsec
12 nsec
15 nsec
12 nsec
17 nsec
0.6 nsec
14 nsec
60 iisec
27 nsec
5 mm deflection at
Input
Capacitance
15 pf
15 pf
47 pf
20 pf
47 pf
50 pf
47 pf
47 pf
20 pf
20 pf
47 pf
500 input Z
47 pf
Adjustable
| 24 pf
1-1
