The Base Station Model Properties window appears.
5 5 Select an RF ID from the RF ID drop-down list.
6 6 Name the Base Station.
Example: "Home Theater MRF-350".
7 7 In the box to the right of each Flasher Port, enter
the name of the piece of gear that the flasher will
be controlling .
Example: Port 1 - AV Receiver
8 8 Click "OK"
9 9 Close the System Configuration window by
clicking on the "Close" icon in the upper
right hand corner of the window.
1 1 0 0 Save the File. In the main toolbar, select "File" and then click on "Save As".
1 1 1 1 The "Save As" window appears. Enter a name for the new File, Example: "Smith Residence rev1" and then
click on the "Save" button.
C C o o n n f f i i g g u u r r i i n n g g R R F F B B a a s s e e S S t t a a t t i i o o n n s s T T y y p p e e i i n n S S e e c c t t i i o o n n T T i i t t l l e e
1 1 5 5
