- Page 1 Translation of the original instruction manual Version 1.3 Updated on 2021-04-20 Instruction manual Machine Mounted Displays MMD9016...
- Page 2 MMD9016 − Instruction manual v1.3 Read these instructions carefully before using and store for future reference. These instructions contain important information about the product, in particular about its intended use, safety, installation, utilisation, maintenance and disposal. Hand over the instructions to the user following installation of the product, and pass the manual on to the new user if the product is resold.
-
Page 3: Table Of Contents
MMD9016 − Instruction manual v1.3 Contents General information about documentation ................4 General information Explanation of safety instructions 1.2.1 Structure of safety instructions 1.2.2 Explanation of signal words Relevant device documentation Symbols Data, figures and modifications Trademarks Copyright General device information ...................... 8... -
Page 4: General Information About Documentation
1 General information about documentation 1.1 General information This instruction manual is intended to ensure safe and efficient handling of MMD9016 industrial monitors – referred to below as "device". All of the safety instructions and handling instructions given in the manual must be obeyed in order to ensure that work is carried out safely. -
Page 5: Explanation Of Signal Words
MMD9016 − Instruction manual v1.3 1.2.2 Explanation of signal words DANGER Indicates an imminent danger. If not avoided, death or severe injury will result. WARNING Indicates a possible danger. If not avoided, death or severe injury could result. CAUTION Indicates a possible danger. If not avoided, light or minor injuries could result. -
Page 6: Relevant Device Documentation
MMD9016 − Instruction manual v1.3 1.3 Relevant device documentation The following documents are decisive to device setup and operation: • This instruction manual: contains information for installation, commissioning and operation of the device along with technical data. • Website: You can download the instruction manual as well as drivers, software, user manuals, leaflets and flyers from the Download area of our website www.ads-tec.de. -
Page 7: Copyright
MMD9016 − Instruction manual v1.3 1.7 Copyright This instruction manual is protected by copyright. For the authorised user, simple usage rights are granted within the scope of the intent of the contract. Any modified use or exploitation of the provided content, particularly duplication, modification or publishing in whatever form is permitted only with the prior consent of ADS-TEC. -
Page 8: General Device Information
MMD9016 − Instruction manual v1.3 2 General device information 2.1 Manufacturer and contact details The manufacturer of the device is ads-tec Industrial IT GmbH. The company is referred to in the following as ADS-TEC. ads-tec Industrial IT GmbH Heinrich-Hertz-Str.1 72622 Nürtingen... - Page 9 MMD9016 − Instruction manual v1.3 The device can be damaged as a result of unauthorised mechanical modifications. Make sure that the device is not drilled, chiselled or perforated and its exterior shape and design is not modified in any way!
-
Page 10: Environmental Conditions
MMD9016 − Instruction manual v1.3 2.4 Environmental conditions ATTENTION Damage caused by heat! If the device is exposed to sunlight or any other light or heat source, it can overheat and suffer damage. Do not expose the device to direct radiation by sunlight or any other light or heat source! -
Page 11: Conformity
MMD9016 − Instruction manual v1.3 2.5 Conformity The manufacturer hereby declares that the product described in this instruction manual complies with all relevant stipulations of the following European directives: • 2011/65/EU, RoHS Directive • 2014/30/EU, EMC Directive • 2014/53/EU, RED Directive •... -
Page 12: Scope Of Delivery
MMD9016 − Instruction manual v1.3 3 Scope of delivery Check that the contents of the package are intact: If there are signs of damage, please contact the manufacturer immediately. The device must not be put into operation. Check that the contents of the package are complete and match your order: 1 x device −... -
Page 13: Interfaces
MMD9016 − Instruction manual v1.3 4 Interfaces 4.1 Interface overview Display port – or – HDMI for transmitting the image signal USB 2.0 type B (slave) for transmitting the signals from the touchscreen Power supply and functional earth © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany... -
Page 14: Power Supply
MMD9016 − Instruction manual v1.3 4.1.1 Power supply Signal Reference potential 0 V Functional earth (The figure shows the socket inside the device) (FE) +24 VDC ± 20 % The electronics are electrically isolated from the housing. Conductor cross sections: −... -
Page 15: Mechanical Installation
MMD9016 − Instruction manual v1.3 5 Mechanical installation 5.1 Requirements Requirement regarding installation location: ATTENTION Damage caused by heat! If the device is exposed to sunlight or any other light or heat source, it can overheat and suffer damage. •... -
Page 16: Attaching Flange Seal
MMD9016 − Instruction manual v1.3 5.2 Attaching flange seal ATTENTION To maintain the IP protection class: Insert the flange seal the right way round The side with the double lip should lie against a flat flange. • The side with the single lip must be pressed into a groove. -
Page 17: Securing To Vesa Interface
MMD9016 − Instruction manual v1.3 5.3 Securing to VESA interface The rear cover has a combined interface for VESA 75 and VESA 100. 1. Press the flange seal evenly into the groove on the housing side (cf. 5.2). 2. Guide all cables through the openings in the seal, flange and rear cover and plug in all connectors. - Page 18 MMD9016 − Instruction manual v1.3 4. Screw down the seal. 3.5 Nm 5. Screw on the rear cover in a crosswise sequence in two stages. Tool: 8 mm spanner, torque: 3.5 Nm 3.5 Nm © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany...
-
Page 19: Securing Using Tube Adapter
MMD9016 − Instruction manual v1.3 5.4 Securing using tube adapter 5.4.1 Attachment variants The tube adapter can be attached to a bottom-mounted or side-mounted tube. Tube diameter: 48.3 mm Example showing attachment to a bottom-mounted tube: WARNING Risk of injury caused by the device slipping off a top-mounted... -
Page 20: Attaching Tube Adapter
MMD9016 − Instruction manual v1.3 5.4.2 Attaching tube adapter 1. Press the flange seal into the groove on the housing side (cf. 5.2). 2. Guide all cables through the opening of the adapter and plug in all connectors. 3. Secure the cables using a cable tie at the fixtures provided. -
Page 21: Screwing Adapter To Retaining Tube
MMD9016 − Instruction manual v1.3 5.4.3 Screwing adapter to retaining tube Holes can be drilled into the retaining tube using the supplied drilling template. The exact procedure is described in the drilling template instructions also supplied. 48.3 mm To screw on the adapter, you may use the threaded pins (ISO4027 M5x8) enclosed with the device. -
Page 22: Commissioning
MMD9016 − Instruction manual v1.3 6 Commissioning ATTENTION Hazard due to condensation Damage to electronic components caused by condensation resulting from temperature fluctuations. Switch on the device only after it has acclimated to the ambient temperature. • ATTENTION Damage due to electrostatic discharge! Damage to the device can be caused by electrostatic discharge. -
Page 23: Cleaning
MMD9016 − Instruction manual v1.3 7 Cleaning How often you need to clean the system depends on your work and the operating environment. If necessary, follow the on-site cleaning plan. Clean and maintain your system regularly. Cleaning agents and disinfectants We recommend cleaning the devices using commercially available glass cleaning agents on a soft cloth. -
Page 24: Dimensional Drawings
MMD9016 − Instruction manual v1.3 9 Dimensional drawings © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany... - Page 25 MMD9016 − Instruction manual v1.3 © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany...
- Page 26 MMD9016 − Instruction manual v1.3 © ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany...
-
Page 27: Technical Data
MMD9016 − Instruction manual v1.3 10 Technical data Housing Fully enclosed stainless steel housing Display Type 15.6" TFT display Aspect ratio 16:9 Resolution 1920 x 1080 pixels Colours 16.2 million Brightness Typ. 400 cd/qm, LED backlight LED service life 50,000 hours up to half brightness Viewing angle 89°... -
Page 28: Service & Support
MMD9016 − Instruction manual v1.3 11 Service & support ADS-TEC and its partner companies offer you comprehensive maintenance and support services, ensuring quick and competent support should you have any questions or concerns with regard to ADS- TEC products and equipment.
