Laser Pegs 9040 SAMURAI Quick Start Manual

Please read manual before you
9040
begin! Failure to follow this manual's
instructions may result in damage to
SAMURAI
the Triangle Power Base, AC Adapter
and/or Laser Pegs®. Not adhering
For Boys And Girls
to these directions will void the
Ages 5 And Up
manufacturer's warranty.
8 Models+
Packing has to be kept since it
Any creation you can build contains important information.
LIGHTED WARNING:
CHOKING HAZARD
CONSTRUCTION SET INCLUDES:
Not for children under 3 yrs.
• 14 Laser Pegs®
Do not submerge in water.
• 42 Construction Parts
• Triangle Power Base
• Instruction Manual
Requires 3 AA Batteries
Batteries NOT
Included
Construction Compatible
Compatible with other
construction kits
EN71, RoHS COMPLIANT
This product complies to all safety
requirements of ASTM F 963
MODEL INSTRUCTIONS MODEL INSTRUCTIONS MODEL INSTRUCTIONS
All additional model instructions can be All additional model instructions can be All additional model instructions can be
downloaded at www.LaserPegs.com downloaded at www.LaserPegs.com downloaded at www.LaserPegs.com
Laser Pegs® Parts List
x1
90°
There is No LED In The Peg
x1
x1 x2
x1
Y PEG
SQUARE 45° PEG SQUARE TRIANGLE STRAIGHT
PEG M-M PEG PEG T-PEG
Color
Each Laser Peg® is color coded on the circuit board inside
Code
each shape. There is No LED In The 90 Degree Peg.
Laser Pegs Stackable
®
Laser Pegs ® link that allows you to
Triangle Power Base
connect to other construction kits.
Construction Parts List
x6
x7 x2
x1
x4
x2
x2 x2
x2
x2
x2
www.LaserPegs.com
This manual is copyright and cannot be reproduced or used online without Laser
Pegs®Ventures LLC permission. Copyright 2013 © All Rights Reserved US Patent
#7,731,558 Additional Global & Multiple Patents Pending. Laser Pegs® Ventures
LLC. 8304 Consumer Ct., Sarasota FL 34240. Contact: Support@LaserPegs.com
Connecting Pegs
To construct with Laser Pegs®, slide two pieces together to form
a connection. Slide each piece on and off smoothly. The 90° pegs
are essential to construction but they DO NOT ILLUMINATE.
Press button to
turn on/off
-
Small parts.
Push button to cycle
through 3 different
light settings.
Peg Holes
Power Button
AC Adapter Connection
When Using Batteries
1. Remove screws.
2. Place three AA batteries in the correct
position - as displayed inside the Triangle Power Base.
3. Push RED button to turn on!
4. Do not mix old and new batteries.
5. Do not mix alkaline, standard (carbon-
zinc), or rechargeable (nickel-cadmium) batteries!
6. Exhausted batteries are to be removed
from the power base.
7. Never connect more than 200 Laser Pegs®
8. Non-rechargeable batteries are not to be recharged.
9. Rechargeable batteries are only to be charged under
adult supervision.
10. Rechargeable batteries are to be removed from the
x4
toy before being charged.
STACKABLE
11. Batteries are to be inserted with the correct polarity.
x2
12. The supply terminals are not to be short-circuited.
Using an
Remove all batteries from Laser Pegs®
x2
power base before using the 5 volt AC
AC Adapter
90° PEG Adapter.
When using an AC Adapter,
NEVER place the adapter
plug into the Triangle Power
Base top peg holes.
*To avoid short-circuits, keep metal objects and other
un-authorized materials from obstructing the peg holes.
The AC adapter used with the power base are to be regularly
x2
examined for damage to the cord, plug, enclosure and other
parts, and in the event of such damage, they must not be used
x2 until the damage has been repaired.
Never connect more than 200 Laser Pegs®
when using a 5 volt (2000mA) AC Adapter.
x2
WARNING! Each Laser Peg® draws current from the batteries. Therefore,
the more pegs you use, the quicker you will deplete your battery power! As
the power weakens, the current will slowly fail and some Laser Pegs® will
illuminate (typically the reds and yellows) and some won't. When the Laser
Pegs® dim the Laser Pegs® are not broken, they just need stronger batteries
4
or an AC adapter.
You have 3 simple options...
1. Use a 5 volt AC Adapter –available from www.LaserPegs.com.
2. Change the batteries.
3. Use high quality batteries. They will last a little longer, but they will still
deplete rapidly the more Laser Pegs® you connect!
GIANT MOTH - A large, nocturnal insect related to butterflies with
a stout body and plain colors.
Remove the three Philips
head screws with a 4mm
screw driver.
Requires (3AA) Batteries
STEP
x6
GIANT MOTH
Model
Difficulty
Level
A
1
