American Dynamics AD615 Quick Reference Manual

This Quick Reference Guide illustrates the screens found in the
DeltaDome Programmable Surveillance Camera Configuration
Utility. The large numbers in the circles represent the number of
the screen. The small numbers appearing to the right of the menu
choices represent the screen you will see if you pick that choice.
Note: The numbers in the circles do not actually appear on the
screens.
To start the configuration utility, do one of the following:
For SensorNet or RS-422, press and hold Iris Open, press and
hold a Focus button, then press Zoom Out.
For Manchester, turn the key switch to Prog (or disable the
system lock on the T
OUCH
66, then press Set Preset..
Refer to the keyboard or T
OUCH
for the locations of the control buttons.
DOME CONFIGURATION MENU
1
PAN/TILT/ZOOM OPTIONS
CAMERA / LENS FUNCTIONS
ALARMS / AREAS / HOME
ON-SCREEN TEXT DISPLAY
LANGUAGE / PASSWORD
EXIT AND SAVE CHANGES
QUIT WITHOUT SAVING
RESET TO FACTORY SETTINGS
NOTE: If password protection is enabled, you must enter the
password before the Dome Configuration Menu will display.
Refer to screen 19 for information.
2 PAN / TILT / ZOOM OPTIONS
PROPORTIONAL FLIP
1ST ZOOM STOP X
MAX TOTAL ZOOM X
RESET TO FACTORY SETTINGS
Settings (Defaults in Bold)
Proportional Flip ON / OFF
1st Zoom Stop X 16 / 24
Max Total Zoom X 32 / 48 / 64 / 80 / 96 / 112 / 128
8000-2613-02, Rev. B
DeltaDome™ Programmable Surveillance Camera
®
T ), use the keypad to enter
RACKER
T operating instructions
RACKER
OFF
24
128
EXIT
1
Configuration Utility Quick Reference Guide
The following table describes the functions of the controls used
to interact with the screens. Where a specific Focus button is not
specified, either the Focus Near or Focus Far button may be used.
Display configuration menu (SensorNet and RS-422
only)
Display configuration menu (Manchester only)
Save and exit utility from any screen (not supported
on Manchester)
Moves highlight bar up
Moves highlight bar down
Moves highlight bar right
Moves highlight bar left
Selects the highlighted item
2
Increases the value or displays the next choice
3
During naming, moves the cursor to the right of the
4
current character in the name
5
6
Decreases the value or displays the previous choice
During naming, moves the cursor to the left of the
current character in the name
3
CAMERA / LENS FUNCTIONS
RESET TO FACTORY SETTINGS
Settings (Defaults in Bold)
Line Lock ON / OFF
AGC Mode ON / OFF
AGC Manual Gain: 0 - 1128*
Auto White Bal ON/OFF
Red White Bal 128-1023**
Blue White Bal 128-1023**
* AGC Mode must be OFF to change
** Auto White Bal must be OFF to change
Function
LINE LOCK
AGC MODE
AGC GAIN
AUTO WHITE BAL
RED WHITE BAL
BLUE WHITE BAL
EXIT
Quick Reference Guide
Control
Iris Open, Focus,
then Zoom Out
Key switch to Prog,
66, then Set Preset
Iris Close then
Focus
Tilt Up
Tilt Down
Pan Right
Pan Left
Focus Far
Zoom In
(Zoom Tele)
Zoom Out
(Zoom Wide)
OFF
ON
112
ON
457
563
1
