- Page 1 ZVconnect WIRELESS PRESENTATION SYSTEM User Guide Updated October 2020...
-
Page 2: Table Of Contents
ZVconnect User Guide Table of Contents System Description Features Receiver Unit Transmitter Unit Operating Guide Receiver Installation Transmitter Installation Full Screen Mirroring Dual Screen Mirroring Synchronization to specific Receiver Battery Status Battery Charging Optional Charging Stand Specifications Transmitters Receiver Certifications and Warranty... -
Page 3: System Description
ZVconnect User Guide System Description The ZVconnect provides a simple, robust conference room video solution. The transmitter plugs directly into your laptop’s video output, and the receiver into the HDMI video input of your display. No drivers or software to install. No USB limitations. -
Page 4: Features
ZVconnect User Guide Features Receiver Unit Blue Flash (1s) : Ready to Play Blue Flash (100ms) : Setting mode Power LED Status LED HDMI Connector USB Type-C Connector Setting Button for DC 5V power Rev 20201020 Page... -
Page 5: Transmitter Unit
ZVconnect User Guide Transmitter Unit Purple: Booting Purple Flash: Factory Reset mode Blue: Ready to Play Blue Flash (1s) : Transmitting Blue Flash (100ms): Setting mode Red: no HDMI source Red Flash (300ms): Checking receiver connection Status LED HDMI or USB-C... -
Page 6: Operating Guide
ZVconnect User Guide Operating Guide Receiver Installation 1. Connect ZVconnect Receiver to HDMI input of display 2. Connect 5V/2A power to ZVconnect receiver 3. Status light will turn blue. Wait for status light to flash. (About 30 seconds) 4. Ready to Play... -
Page 7: Transmitter Installation
ZVconnect User Guide Transmitter Installation 1. Disconnect transmitter from any source 2. Power the transmitter on by holding power button for about 3 seconds 3. Wait for transmitter to complete booting and LED to turn Red. 4. Press and hold the center button until Blue LED flashes (About 3 seconds) 5. - Page 8 ZVconnect User Guide unit has been factory reset. Unit will now auto synchronize to any RX currently in range. If there is no RX unit in range, the transmitter LED will continue to flash purple. To exit Reset Mode, follow the instructions for Synchronizing to a specific receiver starting on page 11 of this document.
-
Page 9: Full Screen Mirroring
ZVconnect User Guide Full Screen Mirroring Once the receiver has completed the boot process the screen shown to the left will appear on the display. Connect either an HDMI or USB-C transmitter to a source. Power on the transmitter Wait for the status LED to turn blue Press the settings/transmit button once. -
Page 10: Dual Screen Mirroring
ZVconnect User Guide Dual Screen Mirroring It is possible to connect two transmitters to a single receiver simultaneously and display the images side by side on the display. This process requires at least two transmitters that are synced to the same receiver. -
Page 11: Synchronization To Specific Receiver
ZVconnect User Guide Synchronization to specific Receiver In cases where there are multiple Receiver units in range, you will want to Synchronize or Pair a Transmitter to a specific Receiver. This is done by putting the Receiver into Pairing Mode and synchronizing it with desired Transmitters. - Page 12 ZVconnect User Guide Step 3: Press Receiver’s center button for 3 seconds. After initialization the “Ready to pair” message will be shown on the lower left corner of the display. The Receiver is now in pairing mode. Rev 20201020 Page...
- Page 13 ZVconnect User Guide Step 4: Press the Transmitter’s power button for 3 seconds and wait until the LED of the center button becomes flashing red. Press and hold the center button until the LED become flashing blue and then release it. The Transmitter will now pair with the Receiver. When the pairing process is successfully completed, “Synchronizing is completed”...
- Page 14 ZVconnect User Guide Step 5: Once pairing is completed, press the Receiver’s center button until you see the “initialization” in the status field to exit pairing mode. Important: You will not be able to transmit video from a Transmitter to Receiver until the Receiver is taken out of pairing mode.
-
Page 15: Battery Status
ZVconnect User Guide Battery Status The transmitter units have an integrated rechargeable battery. The status of the battery is indicated by a series of LED lights on the side of the unit. Battery Status Lights Two green plus One orange = Battery Charge 80% - 100%... -
Page 16: Battery Charging
ZVconnect User Guide Battery Charging To charge transmitter units follow the procedure below: 1. Power off the transmitter 2. Plug the USB-C charging cable into the transmitter 3. Connect other end of charging cable to appropriate USB charging block and power 4. -
Page 17: Optional Charging Stand
ZVconnect User Guide Optional Charging Stand There is an optional charging stand available for the transmitter devices (Part # ZVCCHARGE) that can hold and charge up to 4 ZVconnect transmitters at one time. Note that the ZVconnect transmitter LED will remain while the unit is actively charging and will turn off when the unit is fully charged. -
Page 18: Specifications
ZVconnect User Guide Specifications Transmitters Model Number ZVCTXHDMI ZVCTXUSBC Description/Interface Wireless transmitter with HDMI Wireless transmitter with USB-C interface interface In the box Transmitter, USB cable, 2A USB Transmitter, USB cable, 2A USB power block power block Video Codec H.265 H.265... -
Page 19: Receiver
ZVconnect User Guide Receiver Model Number ZVCRXHDMI Description/Interface Wireless receiver with HDMI interface In the box Receiver, USB cable, 2A USB power block Video Codec H.265 Resolution 3840 x 2160 @60Hz*, 1920 x 1080 @60Hz*, 1920 x 1200 @60Hz* WLAN IEEE802.11a/b/g/n/ac... -
Page 20: Part Numbers
Charging cradle unit to simultaneously charge up to 4 cradle for up to 4 ZVconnect ZVconnect transmitter units. Includes cradle and transmitters power supply/cable. ZVconnect wireless room kit with HDMI transmitters. ZVconnect wireless system Includes 1 receiver unit and 2 transmitter units with room kit with HDMI ZVCKITH HDMI inputs. -
Page 21: Disclaimers
ZeeVee hardware designs are property of ZeeVee. Components, sub-assemblies, and methods utilized in the designs are free of any encumbrances or appropriate licenses and rights have been obtained by ZeeVee for the use in the described products in the intended manner.
