EASYDRAPE
SUPPORT BRACE

Advertisement

loading
Need help?

Need help?

Do you have a question about the EASYDRAPE and is the answer not in the manual?

Questions and answers

Related Manuals for ShowTex EASYDRAPE

Summary of Contents for ShowTex EASYDRAPE

  • Page 1 EASYDRAPE SUPPORT BRACE...
  • Page 2 COMPONENTS Create unlimited EasyDrape con gurations using these di erent parts. EasyDrape Installation Manual...
  • Page 3 ASSEMBLY Place 2 base plates at the desired distance apart Attach the base plate connectors to the base plates (page 7) Attach an Upright to one of the plates (page 8) EasyDrape Installation Manual...
  • Page 4 ASSEMBLY Attach the base plate connectors to the base plates and position the EasyDrape base plates at the desired distance apart. When positioning the base plate connectors in the base plates, make sure the two holes in the sides of the connector are lined up in the same direction as the small markings in the base plate.
  • Page 5 Attach the Uprights to the plates and the four way adaptor piece to the Uprights Hammer the pin into the larger of the two holes in the upright. [tooltip] use the EasyDrape Tool to hammer in the pins EasyDrape Installation Manual...
  • Page 6 Attach an extension to the Upright with one conical coupler. Hammer the pins into the larger of the two holes. Use safety R-springs to secure the two curved supports to each other. [tooltip] use the EasyDrape Tool to hammer in the pins EasyDrape Installation Manual...
  • Page 7 Attach a hinge to the other Upright using a half conical coupler. Use the EasyDrape Tool to hammer the pin into the larger of the two holes in the coupler. Use a safety R-spring to secure the coupler to the Upright and screw the hinge to the coupler.
  • Page 8 ASSEMBLY Attach the Upright to the Base Plate. Use the EasyDrape Tool to hammer the pin into the larger of the two holes of the hinge. Use a safety R-spring to secure the hinge to the Base Plate. [tooltip] use the EasyDrape Tool...
  • Page 9 First screw the half conical coupler to the hinge using a nut, and attach the hinge to the Upright. Use the EasyDrape Tool to hammer the pin into the larger of the two holes in the coupler. Use a safety R-spring to secure the coupler to the Upright and.
  • Page 10 Hammer the pin into the larger of the two holes of the hinges. Use safety R-springs to secure the two hinges together. Next attach the two hinges together using a pin and R-spring. [tooltip] use the EasyDrape Tool to hammer in the pin EasyDrape...
  • Page 11 ASSEMBLY Attach the clamp to the larger upright and you’re ready to roll! EasyDrape Installation Manual...

  • Page 12: Troubleshooting

    TROUBLE SHOOTING • For more technical assistance please contact your local ShowTex office. EasyDrape Installation Manual...
