ShowTex EASYDRAPE Installation Manual

Hide thumbs Also See for EASYDRAPE:

Advertisement

Quick Links

Download this manual
EASYDRAPE
INSTALLATION MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the EASYDRAPE and is the answer not in the manual?

Questions and answers

Related Manuals for ShowTex EASYDRAPE

Summary of Contents for ShowTex EASYDRAPE

  • Page 1 EASYDRAPE INSTALLATION MANUAL...

  • Page 2: Table Of Contents

    (3) Attach the four way adaptor piece to the Telescoping Uprights ............08 (4) Attach the horizontal drape support ......................09 (5) Extend the EasyDrape assembly horizontally..................... 10 (6) Hang the curtains ..............................11 (7) Extend the EasyDrape assembly vertically....................12 Maintenance Instructions ..............................
  • Page 3 Combine with ShowPipe track system for curtain motion. • Connect to a curved pipe to create free standing tunnels. • Use EasyDrape instead of a truss to save time and space. • Hang expo drapes and starcloths from 2-5 meters high. •...

  • Page 4: Safety Instructions

    Read this user manual carefully. In order to prevent potential damage to equipment and/or injury to personnel these instructions must be understood and followed. • Only combine with parts and accessories from the ShowTex curtain track range. • EasyDrape couplers are not t for trussing.

  • Page 5: Components

    COMPONENTS Create unlimited EasyDrape con gurations using these di erent parts. EasyDrape Installation Manual...

  • Page 6: Installation

    ASSEMBLY Attach the base plate connectors to the base plates and position the EasyDrape base plates at the desired distance apart. When positioning the base plate connectors in the base plates, make sure the two holes in the sides of the connector are lined up in the same direction as the small markings in the base plate.
  • Page 7 Attach the Uprights to the plates and the four way adaptor piece to the Uprights Hammer the pin into the larger of the two holes in the upright. [tooltip] use the EasyDrape Tool to hammer in the pins EasyDrape Installation Manual...
  • Page 8 ASSEMBLY Secure the four way adaptor pieces and the Uprights Use a safety R-spring to secure the Uprights to the plates and the base plate connectors to the Uprights. EasyDrape Installation Manual...

  • Page 9: Attach The Horizontal Drape Support

    Attach the horizontal drape support to the four way adaptor piece of each Upright Hinges are tted to both ends of the horizontal drape support thus enabling the end-user to assemble one side of the EasyDrape by him/herself while the other side rests on the oor. [slide]...

  • Page 10: Extend The Easydrape Assembly Horizontally

    ASSEMBLY Extend the EasyDrape assembly horizontally to the desired width Don’t forget to loosen the screw when extending the drape support. EasyDrape Installation Manual...
  • Page 11 ASSEMBLY Hang drapes, starcloths, or other fabrics measuring 2 to 5 metres in height on the drape supports with Velcro. EasyDrape Installation Manual...

  • Page 12: Extend The Easydrape Assembly Vertically

    ASSEMBLY Extend the EasyDrape assembly vertically to the desired height Don’t forget to loosen the screw when extending the Uprights. EasyDrape Installation Manual...
  • Page 13 ASSEMBLY You’re now ready to roll! EasyDrape Installation Manual...
