JBL Soundpoint SP6 Series Technical Manual

Technical Manual
SP6
Soundpoint
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance
• Max Amp Power
• Frequency Response
• Sensitivity
• Crossover Frequency
SYSTEM COMPONENTS:
• Grille, Gray
• Low-Frequency Transducer
DC Resistance
• High-Frequency Transducer
DC Resistance
• Crossover Network
PACKAGING
5
4
3
JBL Consumer Products, 250 Crossways Park Drive, Woodbury, New York 11797
™ Series
8 ohms
80 watts*
38Hz – 20kHz (–10dB)
88dB (2.83V @ 1 meter)
2,800Hz
129-0005
6-1/2" (165mm) titanium-lami-
nate cone w/rubber surround
(330-0139)
5.9 ohms
1" (25mm) titanium-laminate
dome, w/swivel mount
(300-0080)
7.9 ohms ±10%
340-0118
Legend on Page 2
12
2
6
AURAL SWEEP TEST SPECIFICATIONS:
• System Aural Sweep Test
• L.F. Aural Sweep Test
• H.F. Aural Sweep Test
PHYSICAL SPECIFICATIONS:
• Plate Size (W x H)
• Mounting Cutout
Size (W x H)
• Mounting Depth
• Weight
WARRANTY:
• Refer to Warranty Statement packed with each product.
* The maximum recommended amplifier power rating will ensure
proper system headroom to allow for occasional peaks. We do not
recommend sustained operation at these maximum power levels.
CROSSOVER NETWORK
340-0118
L1
1.6mH
2.7 ohms
10 watts
C2
7uF
L2
100V
0.5mH
6.0V Input 35Hz to 20kHz
5.0V Input 35Hz to 3kHz
2.83V Input 2kHz to 20kHz
8-1/2" x 11" (216mm x 297mm)
7-1/8" x 9-11/16"
(181mm x 246mm)
3-7/8" (98mm)
10 lb (4.5kg) Sold in pairs
GRN
.250
C1
16uF
100V
BLK
.205
R1
YEL
.110
R2
7.5 ohms
10 watts
BLK
.110
Rev 4 1/06
