Technical Manual
S1S-EX
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance
• Max Amp Power
• Frequency Response
• Sensitivity
SYSTEM COMPONENTS:
• Low-Frequency Transducer 2242HPL 18" (457mm)
DC Resistance
PACKAGING
3
X 4
4
2
JBL Consumer Products, 250 Crossways Park Drive, Woodbury, New York 11797
Synthesis One/Hercules
8Ω
800 watts*
20Hz – 200Hz
97dB @ 50Hz
Cone transducer
301361-003
4.7 ohms ±10%
2
1
Legend on Page 2
AURAL SWEEP TEST SPECIFICATIONS:
• L.F. Aural Sweep Test
PHYSICAL SPECIFICATIONS:
• Enclosure Dimensions
(H x W x D)
• Weight
WARRANTY:
• Refer to Warranty Statement packed with each product.
* The maximum recommended amplifier power rating will
ensure proper system headroom to allow for occasional
peaks. We do not recommend sustained operation at
these maximum power levels.
LOW-FREQUENCY
TRANSDUCER
301361-003
S1S-EX SCHEMATIC
INPUT
15.0V Input 16Hz to 250Hz
34-1/2" x 21" x 22"
(876mm x 533mm x 559mm)
plus knobs
129 lb (58.5kg) Each
GRN
+
—
GRN/BLK
TERMINAL CUP
352303-001
27" GRN
L.F.
27" GRN/BLK
7/04
