INSTALLER: LEAVE THESE INSTRUCTIONS WITH THE APPLIANCE
INSTALLATION MANUAL
Gas 30-inch Wide Free-Standing Range
PLEASE KEEP THIS MANUAL FOR FUTURE REFERENCE
THE MANUAL IS INTENDED TO ASSIST IN THE INITIAL INSTALLATION AND ADJUSTMENTS OF THE RANGE.
SPECIAL WARNING
Only qualified personnel should
install or service this range.
Read "Safety Instructions" in the
Use & Care book before using
range.
Improper installation, adjustment,
alteration, service, maintenance or
use of range can result in serious
injury or property damage.
· ALL RANGES CAN TIP AND
CAUSE INJURIES TO PERSONS.
· INSTALL
PACKED WITH RANGE.
· FOLLOW ALL INSTALLATION
INSTRUCTIONS.
Your range may not be equipped with
some of the features referred to in this
manual.
ANTI-TIP
DEVICES

CLEARANCE DIMENSIONS

Range may be installed with zero inches clearance
adjacent to (against) combustible construction at the rear
and on the sides below the cooktop. For complete
information in regard to the installation of wall cabinets
above the range and clearances to combustible wall
above the cooking top see the installation drawings. For
SAFETY CONSIDERATIONS do not install a range in any
combustible cabinetry which is not in accord with the
installation drawings.
*
NOTE: 30 inch (76.2 cm) dimension between cooking
top and wall cabinet shown on illustration does not apply
to ranges with an elevated oven. The installation
instructions of the elevated oven will specify the
minimum acceptable dimension between the cooktop
and elevated oven. The 30 inch (76.2 cm) dimension
may be reduced to not less than 24 inches (61 cm) when
the wall cabinets in a domestic home are protected with
fireproof materials in accordance with American National
Standards - National Fuel Gas Code or in mobile homes
when they are protected with fireproof materials in
accordance with the Federal Standard for Mobile Home
Construction and Safety.
To eliminate the risk of burns or fire by reaching over
heated surface units, cabinet storage space located
above the surface units should be avoided. If cabinet
storage is to be provided, the risk can be reduced by
installing a range hood that projects horizontally a
minimum of 5 inches (13 cm) beyond the bottom of the
cabinets.
CAUTION:
This range has been designed in
accordance with the requirements of various safety
agencies and complies with the maximum allowable
wood cabinet temperatures of 194°F. If this range
is installed with cabinets that have a lower working
temperature than 194°F, discoloration, delamination
or melting may occur.
8101P571-60
(11-03-01)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AGR5835QDW and is the answer not in the manual?

Questions and answers

Summary of Contents for Amana AGR5835QDW

  • Page 1: Clearance Dimensions

    INSTALLER: LEAVE THESE INSTRUCTIONS WITH THE APPLIANCE INSTALLATION MANUAL Gas 30-inch Wide Free-Standing Range PLEASE KEEP THIS MANUAL FOR FUTURE REFERENCE THE MANUAL IS INTENDED TO ASSIST IN THE INITIAL INSTALLATION AND ADJUSTMENTS OF THE RANGE. SPECIAL WARNING Only qualified personnel should install or service this range.
  • Page 2: Installation Drawings

    INSTALLATION DRAWINGS FREE-STANDING RECOMMENDED GAS SUPPLY AND/OR 120 VOLT GROUNDED FLUSH MOUNT ELECTRICAL OUTLET LOCATION. GAS AND ELECTRICAL SUPPLY SHOULD NOT CONVERGE. DO NOT GROUND ELECTRICAL SUPPLY TO GAS SUPPLY LINES. NOTE: TO ENSURE FLUSH TO WALL INSTALLATION GAS SERVICE INCLUDING SHUT-OFF VALVE SHOULD NOT PROTRUDE MORE THAN 3²...
  • Page 3: Mobile Homes

    DIMENSION “A” SIDE CLEARANCE ABOVE COOKING SURFACE = 3 INCHES (7.6 CM) (MINIMUM) Check the range model number plate located on lower front of range to see if the range is approved for installation in mobile homes and/or recreational park trailers.
  • Page 4 ANTI-TIP DEVICE INSTALLATION INSTRUCTIONS NOTE: A risk of range tip over exists if the appliance is not installed in accordance with the installation instructions provided. The proper use of this device minimizes the risk of TIP-OVER. In using this device the consumer must still observe the safety precautions as stated in the USE and CARE MANUAL and avoid using the oven door and/or lower drawer as a step stool.
  • Page 5: Connecting The Range

    CONNECTING THE RANGE Electric Supply The appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70. In Canada the range must be installed in accordance with the current CSA Standard C22.1 - Canadian Electrical Code Part 1.
  • Page 6 Recommended Gas Supply Connections 3/8² FLEXIBLE ADAPTER SUPPLY LINE 1/2² NPT MALE TO 3/8² NPT FEMALE ADAPTER BUSHING REGULATOR REGULATOR SHUT-OFF VALVE 1/2² NPT MALE TO 3/8² NPT FEMALE ADAPTER BUSHING REGULATOR REGULATOR SHUT-OFF VALVE FIGURE 3 WHEN THE INSTALLER HAS COMPLETED INSTALLATION OF THE APPLIANCE, LEAVE THE APPLIANCE PRESSURE REGULATOR SHUT-OFF VALVE IN THE “ON”...
  • Page 7: Gas Conversion

    RANGE ADJUSTMENTS Top Section - Electric Ignition To operate, push and turn top burner knob to the LITE position. The top burner will light. To turn OFF spark after the top burner has ignited, turn knob to HI setting. NOTE: Top burners are not adjustable. Air Shutter - Bake/Broil Burner NOTE: If oven burner does not ignite, check oven gas shut-off position at the regulator.
  • Page 8: Service/Parts Information

    Appliance Pressure Regulator Conversion The unit appliance pressure regulator must be set to match the type gas supply used. If converting from natural gas to LP gas, the appliance pressure regulator must be converted to regulate LP gas. If converting from LP gas to natural gas, the appliance pressure regulator must be converted to regulate natural gas.
  • Page 9: Manual De Instalación

    INSTALADOR: DEJE ESTAS INSTRUCCIONES CON EL ELECTRODOMÉSTICO MANUAL DE INSTALACIÓN Estufa independiente convencional de CONSERVE ESTE MANUAL COMO REFERENCIA FUTURA EL MANUAL TIENE LA FINALIDAD DE AYUDARLE EN LA INSTALACIÓN Y LOS AJUSTES INICIALES ADVERTENCIA ESPECIAL Solamente el personal calificado deberá...
  • Page 10 DIBUJOS DE INSTALACIÓN INDEPENDIENTE RECOMENDACIÓN PARA EL SUMINISTRO DE GAS Y/O LA UBICACIÓN DEL TOMACORRIENTE ELÉCTRICO DE 120 VOLTIOS, MONTADO AL RAS Y CONECTADO A TIERRA. ALTURA A LA PARTE SUPERIOR DEL MOSTRADOR 91.5 CM (36”) EL SUMINISTRO DE GAS Y EL ELÉCTRICO NO DEBEN CONVERGIR. NO CONECTE EL SUMINISTRO ELÉCTRICO A TIERRA USANDO LAS TUBERÍAS DE SUMINISTRO DE GAS.
  • Page 11: Ubicación De La Estufa

    45.7 CM (18”) MÍNIMO LA DIMENSIÓN “A” DEL ESPACIO LIBRE POR ENCIMA DE LA SUPERFICIE PARA COCINAR ES = Lea la placa de datos de la estufa ubicada en la parte delantera inferior de la estufa para ver si está aprobada la instalación en casas móviles o vehículos recreativos.
  • Page 12 INSTRUCCIONES DE INSTALACIÓN DEL DISPOSITIVO ESTABILIZADOR NOTA: Existe el riesgo de que la estufa se voltee si el electrodoméstico no se instala de acuerdo con las instrucciones de instalación provistas. El uso correcto de este dispositivo reduce el riesgo de VOLTEO. Cuando se use este dispositivo el propietario debe aún observar las precauciones de seguridad según se indican en el MANUAL DE USO Y CUIDADO y evitar usar la puerta del...
  • Page 13 CONEXIÓN DE LA ESTUFA Suministro de energía eléctrica El electrodoméstico, cuando se instala, debe conectarse a tierra de acuerdo con los códigos locales o, si no exis- tieran, con el Código Nacional Eléctrico, ANSI/NFPA 70. En Canadá la estufa debe instalarse de acuerdo con la Norma actual C22.1 de CSA —...
  • Page 14 Conexiones recomendadas del suministro de gas TUBERÍA FLEXIBLE DE ADAPTADOR ROSCADO NPT SUMINISTRO DE .95 cm (3/8²) DE .95 cm (3/8²) CASQUILLO ADAPTADOR MACHO DE 1.27 cm (1/2”) NPT A HEMBRA DE .95 cm (3/8²) NPT REGULADOR ON (encendido) VÁLVULA DE CIERRE DEL OFF (apagado) REGULADOR...
  • Page 15: Conversión De Gas

    AJUSTES DE LA ESTUFA Sección superior — Encendido electrónico Para que funcione, empuje y gire la perilla del quemador superior a la posición de encender “LITE”. El quemador superior se encenderá. Para APAGAR la chispa después de que se haya encendido el quemador superior, gire la perilla al ajuste alto “HI”.
  • Page 16 Conversión del regulador de presión del electrodoméstico El regulador de presión de la unidad debe estar ajustado para el tipo de gas que se suministrará. Si se convertirá el gas natural a gas LP, el regulador de presión debe convertirse para que regule el gas LP. Si se convertirá de gas LP a gas natural, el regulador de presión debe convertirse para que regule el gas natural.
  • Page 17 INSTALLATEUR: VEUILLEZ LAISSER CES INSTRUCTIONS AVEC L’APPAREIL MANUEL DE MISE EN SERVICE Cuisinière à gaz amovible de 76,2 cm (30 pouces) VEUILLEZ CONSERVER CE MANUEL POUR RÉFÉRENCE CE MANUEL EST DESTINÉ À FACILITER LA MISE EN SERVICE ET LE RÉGLAGE INITIAUX DE LA CUISINIÈRE. AVERTISSEMENT SPÉCIAL La mise en service et le dépannage de cette cuisinière doivent être réalisés...
  • Page 18 SCHÉMAS DE MISE EN SERVICE AMOVIBLE EMPLACEMENT RECOMMANDÉ POUR L’ALIMENTATION EN GAZ ET/OU UNE PRISE ÉLECTRIQUE MURALE ENCASTRÉE DE 120 V RELIÉE À LA TERRE. DESSUS DE COMPTOIR À 91,5 CM (36 PO) DE HAUTEUR L’ALIMENTATION ÉLECTRIQUE ET CELLE DE GAZ NE DOIVENT PAS CONVERGER. NE PAS EFFECTUER LE RACCORDEMENT À...
  • Page 19: Emplacement De La Cuisinière

    76,2 CM (30 PO) 45,7 CM (18 PO) MINIMUM DIMENSION A, DÉGAGEMENT LATÉRAL AU-DESSUS DE LA SURFACE DE CUISSON = Vérifier sur la plaque signalétique, située dans la partie inférieure de l’avant de la cuisinière, si elle est homologuée pour la mise en service dans une maison mobile et/ou une roulotte de plaisance.
  • Page 20 ANTI-MISE EN PLACE DU SUPPORT DE STABILISATION REMARQUE : La cuisinière risque de basculer si elle n’est pas mise en place conformément aux instructions fournies. Si le dispositif de stabilisation est utilisé correctement, il réduit le risque que la cuisinière ne - BASCULE.
  • Page 21: Raccordement De La Cuisinière

    RACCORDEMENT DE LA CUISINIÈRE Alimentation électrique Une fois en place, l’appareil doit être relié à la terre conformément aux codes locaux ou, en l’absence de codes locaux, aux normes ANSI/NFPA 70 du National Electrical Code. Au Canada, le raccordement de la cuisinière doit être conforme à...
  • Page 22 Raccordement à l’alimentation en gaz recommandé CONDUITE ADAPTATEUR MÂLE--FEMELLE D’ALIMENTATION DE 3/8 PO NPT FLEXIBLE DE 3/8 PO DOUILLE DE RÉDUCTION 1/2 PO NPT MÂLE À 3/8 PO NPT FEMELLE DÉTENDEUR MARCHE DÉTENDEUR ARRÊT ROBINET D’ARRÊT DOUILLE DE RÉDUCTION 1/2 PO NPT MÂLE À...
  • Page 23 RÉGLAGES DE LA CUISINIÈRE Partie supérieure - Allumage électrique Pour allumer un brûleur de la surface de cuisson, pousser sur le bouton de commande correspondant et le mettre sur la position LITE. Le brûleur s’allume. Pour CESSER la production d’étincelles une fois le brûleur allumé, tourner le bouton sur le réglage HI.
  • Page 24 Conversion du détendeur de l’appareil Le détendeur de l’appareil doit être réglé en fonction du type de gaz utilisé. Pour une conversion du gaz naturel au gaz GPL, le détendeur doit être converti de façon à ce qu’il assure la régulation de la pression du gaz GPL. Pour une conversion du gaz GPL au gaz naturel, le détendeur doit être converti de façon à...
