Features - Alaris Medical Systems MedSystem III Directions For Use Manual

Multi-channel Fluid Delivery System
The instrument combines three independent infusion
channels in an unparalleled small size.
Lightweight/portable
The pump with pole clamp weighs just over 5 pounds and
is easy to transport.
Unique, rotating pole clamp
The pump may be attached to a variety of surfaces.
Dose Rate Calculator (DRC)
The pump calculates a volumetric or dose rate based on
values entered for patient weight, drug concentration (drug
amount and diluent volume) and dosing parameters.
Drug List Editor (DLE)
The pump drug list can be customized using Drug List
Editor software.
Six Device Types available
Six available Device Types with configurable parameters
(maximum and minimum rates, maximum volumes,
baseline and maximum pressures, and air-in-line thresholds)
to achieve specific clinical applications:
General Purpose
Neonatal
Controller Pressure
Free-flow Protection
The MedSystem III® system Administration Sets contain a
cassette that provides protection from free-flow conditions.
To remove the cassette from the pump, the cassette's slide
clamp is pulled to full extension, occluding the tubing and
preventing fluid from flowing.
2 INTRODUCTION

Features

Operating Room
General Purpose II
Operating Room II
®
STANDARD MORE START
O N / O F F
DISPLAY OPTIONS STOP
® ® DLE
A B C
A: Stopped
DRUG? Wt ---- KG= 0.0 LB
A:Conc ------- mg/---- ml
A:Dose ------- mcg/kg/min
A:Rate ------- ml/h
A:VR 1 ml (Vol Rem)
A:VI 0 ml DI 0.0 mg
Press Select to choose line
Clear
Select
