Amana AER5845RAB Dimension Manual

25"
36"
C

NOTES:

1. Provide for 120/208, 120/240 volt outlet per applicable cord in this area.
16" (40.6 cm) W x 5 /
3
4
2. Depth excluding handle. Dimension given is from wall to front of oven door.
3 . May vary slightly depending upon leveling legs.
Important:Because of continuing product improvements, Amana reserves the right to change specifications without notice. Dimensional specifications are provided for
planning purposes only. For complete details see installation instructions that accompany each product before selecting cabinetry, making cutouts or beginning installation.
30" FREE-STANDING ELECTRIC RANGE
ELECTRIC
SUPPLY
1
LOCATION
7"
16"
7"
5 / "
3
4
/ "
2 1
4
30"
D
A
" (14.6 cm) H, located 7" from side wall.
24"
Style of product may vary from picture

PRODUCT DIMENSIONS

INCHES CENTIMETERS
A
2
26 5/8
B
29 7/8
C
3
36
D
3
47 3/8

MODEL SKUs

AER5845RAW
AER5845RAB
AER5845RAS
2005-11-21 at 08:24:35 CST
67.6
75.9
91.4
120.3
