Related Manuals for Sol*Aire Vitra VIT10
Summary of Contents for Sol*Aire Vitra VIT10
- Page 1 Vitra Vitra (s2) Instruction Manual...
-
Page 2: Table Of Contents
Contents Safety Instructions Page 3 Installation Instructions Page 4-5 Control Panel Page 6 Manual Operation Page 7 Connecting to WiFi Page 8-9 Controlling the heater Page 10-11 ERP Label Page 12-13 Warranty and Disposal Page 14... -
Page 3: Safety Instructions
Safety Instuctions Read the manual before using the heater. Keep the manual for future reference. Before use, check that the heater and its accessories are complete and intact. The heater must be installed as per installation instructions. The heater must be plugged into a socket that meets the following requirements: AC 230V, frequency 50/60Hz. -
Page 4: Installation Instructions
Installation Instructions Before installing, check that all parts are complete, and the product is intact. The below clearances are required: Bottom = 50mm Top = 200mm Sides = 50mm If you want to use the heater freestanding, please fit the Caldo / Vitra Feet, following the instructions below. - Page 5 Aim the 4 holes in the back of the heater to the 4 hooks on the wall bracket and push it on. Then slide into the slot to click on, as shown below. Fix the wall bracket lock piece onto the bracket with screws, slide the lock piece into the locking slot on the back of the heater, then tighten the screw, as shown in the picture below.
-
Page 6: Control Panel
Control Panel Displays Temperature or Timer Settings Current Temperature Keyboard Lock Up Button Down Button ON/OFF Button Press = Change Display Brightness Button Boost Button Hold = Toggle WiFi Mode WiFi Mode Active Comfort Anti Frost Mode Mode Boost Function From the control panel on the front of the Caldo and Vitra heaters, the user can boost the heating. -
Page 7: Manual Operation
Manual Operation - Without WiFi The Vitra is primarily a WiFi controlled heater. However, for cases where WiFi connectivity is not available , the Vitra can be programmed manually using the control panel on the front of the heater. • After switching on, the heater will beep once and enter standby mode. -
Page 8: Connecting To Wifi
Connecting to WiFi Download the APP onto your smart phone or tablet. You can find the app by scanning the QR code below or searching “SolAire WiFi IQ” in the Google Play or Apple app store. You will need to create an account, unless you already have an account. Create an account by tapping Register. - Page 9 The app will then display its connecting screen. If the heater fails to connect, press and hold the button for 3 seconds. It will switch to its secondary connection (AP) mode. Then follow the steps on the App for the AP mode. The heater will beep and display a solid WiFi icon once the device is connected.
-
Page 10: Controlling The Heater
Controlling the Heater When the heater is online, tap the device name to go to the control interface. Note: when the heater is offline, you will not be able to control it with the app. Temperature calibration If the heater reports a temperature that differs from the actual room temperature the thermostat can be re calibrated. - Page 11 Using the WiFi App You can create a heating schedule to program the heater through the day. The APP displays the schedule as a graph. Tap and Drag your finger on the screen to programme the heater. The App will then let you pick from 3 heating modes: Comfort, Eco and Anti Frost. The temperature of these heating modes can be set to any temperature the you desire Other Features Scenes...
- Page 12 Other control op�ons (mul�ple selec�ons possible) room temperature control, with presence room temperature control, with open win- with distance control op�on with adap�ve start control with working �me limita�on with black bulb sensor Contact details Sol*Aire Hea�ng Products Limited...
- Page 13 Other control op�ons (mul�ple selec�ons possible) room temperature control, with presence room temperature control, with open win- with distance control op�on with adap�ve start control with working �me limita�on with black bulb sensor Contact details Sol*Aire Hea�ng Products Limited...
- Page 14 • Damage caused by non-observance of the user manual, e.g. connection to an unsuitable mains supply or non- compliance with the installation instructions • Partially or completely dismantled appliances Sol*Aire Heating Products Big Shed New Row DL11 7AW Email: info@solairehp.co.uk...
