- Page 1 RA MINI IN-LINE ACTUATOR SERIES User Manual www.regner.es...
- Page 2 © SEPTEMBER 2018 | Regner Engineering SLU | All rights reserved Specifications are subject to change without prior notice. It is the responsibility of the product user to determine the suitability of REGNER® products for a specific application. The product shown in this document is a component.
-
Page 3: Table Of Contents
RA MINI IN-LINE ACTUATOR SERIES 00. TABLE OF CONTENTS 01. FOREWORD ............................04 02. SAFETY ..............................04 03. WARRANTY ............................05 04. SPECIFICATIONS ..........................06 05. INSTALLATION ...........................08 06. MAINTENANCE ..........................10 07. TROUBLESHOOTING........................10 08. APPLICATION POLICY ........................11 09. CONTACT ..............................11... -
Page 4: Foreword
02.01. Safety instructions Please follow these safety guidelines: Thank you for choosing a REGNER® electric linear • Only properly qualified personeel are permitted actuator. REGNER® actuators are high-end products, to perform mechanical and electrical installation carefully designed and manufactured with premium of this product. -
Page 5: Warranty
In case of doubt regarding the existence of a defect or if an inspection is required, REGNER® reserves the right to request the return of the product. Any addi- tional warranty obligations for parts replaced free of... -
Page 6: Specifications
Optional. Customer’s reference for the product. 03. Batch. No.: XXXXXX Identification number assigned to a particular lot of products that enables REGNER® to control the pro- duct quality and tracing of the constituent parts. 04. Symbols. 1. Front rod end The following symbols may be used on the label. - Page 7 RA MINI IN-LINE ACTUATOR SERIES 04.03. Operation environment 04.05. Dimensions The operation temperature range is between +5 to +40º Celsius (+41 to +104 º Farenheit). The protec- tion degree is IP54 (protection against water and dust). Min. 10 ºC Max. +40 ºC IP54 (+14 ºF) (+104 ºF)
-
Page 8: Installation
Speed - Force Current - Force REGNER® actuators can be easy installed by slipping pins through the holes on each end. Mounting pins must be parallel to each other, otherwise actuator may bend and result in damage. - Page 9 Standard connector: MOLEX 39-01-3029 Standard connector MOLEX 39-01-3029 (View From Wire Insertion End) WARNING! REGNER®’s actuators are not designed to be used in the following applications: aircrafts and aerospace, explosive environments, nuclear power generation and offshore installations.
-
Page 10: Maintenance
(if 2. Customer any). fuse burned. B. Check wire 3. Cable connection on damaged. control unit. C. Please contact REGNER®. -
Page 11: Application Policy
REGNER® product related to a customer application. C. Please REGNER® products are applicable for a wide range of contact applications (including healthcare, household equi- REGNER®. pment, and industrial areas). REGNER® cannot know Motor runs but 1. - Page 12 Ripollès, 4 | 17181 Aiguaviva (Girona) SPAIN | Tel. +34 972 476 911 | Fax. +34 972 475 803 info@regner.es | www.regner.es...
