- Page 1 RA67 IN-LINE ACTUATOR SERIES User Manual www.regner.es...
- Page 2 Specifications are subject to change without notice. It is the responsibility of the user to determine the suitability of REGNER® products for a specific application. No part of this publication may be reproduced without written permission from Regner Engineering SLU.
-
Page 3: Table Of Contents
RA67 IN-LINE ACTUATOR SERIES 00. Contents 01. Preface ..............4 02. Safety ..............4 03. Warranty ............... 5 04. Specifications ............6 05. Installation ............9 06. Maintenance ............10 07. Troubleshooting............ 11 08. Application Policy ..........11 09. Contact ..............11... -
Page 4: Preface
• Only properly qualified personnel can perform me- chanical and electrical installation of the actuator. • Do not mount, dismount or perform maintenance Thank you for choosing a REGNER® electric linear work while the actuator is in operation. actuator. REGNER® actuators are high-tech products, •... -
Page 5: Warranty
03.01. Warranty Exclusions Failure to follow these instructions can result in serious personal injury. REGNER® is entitled to deny any warranty if: • The actuator has not been used correctly or its usage specifications (load, temperature, duty cycle, voltage, current, etc.) have not been respected. -
Page 6: Specifications
& Limit switches) 02. Actuator specifications Basic specifications and actuator features. 03. Batch No.: XXXXXX Identification number assigned to a particular lot of products that enables REGNER® to control their quality and trace their constituent parts. 04. Symbols 1. Track Symbol Norms 2. - Page 7 RA67 IN-LINE ACTUATOR SERIES 04.03. Specifications Position Feedback Specifications Supply Voltage 5 VDC Actuator Specifications Output Analog Output Max. Load 6000 N push 0.3 - 3.0 VDC ± 3% 4000 N pull Lead 4 mm Different feedback options for easy integration Max.
-
Page 8: Installation
RA67 IN-LINE ACTUATOR SERIES 05. Installation 04.06. Dimensions 05.01. Mechanical Installation To install the RA67 actuator, simply slip a 010mm pin through the rear mounting hole and use two M10 screws to fasten the track to the moving part of your assembly. - Page 9 WARNING! • Do not work on the actuator or the wiring with the REGNER® actuators are not designed to be used in power switched on! the following applications: aircraft, explosive envi- ronments, nuclear power generators, and offshore installations.
-
Page 10: Maintenance
RA67 IN-LINE ACTUATOR SERIES 07. Troubleshooting 06. Maintenance The actuator is a closed unit and does not require Symptom Possible cause Action internal maintenance. In fact, the actuator is not to The motor pro- 1. Actuator A. Check the con- be opened by unauthorized personnel. -
Page 11: Application Policy
Hall sensor. connected to the power supply or REGNER® products can be used in a wide range of power supply. the control unit, applications in health care, household or industrial if any. 2. Burned fuse. - Page 12 Ripollès, 4 | 17181 Aiguaviva (Girona) SPAIN | Tel. +34 972 476 911 | Fax +34 972 475 803 info@regner.es | www.regner.es...
