SAFETY PRECAUTION
CAUTION:
The lightning flash with
arrowhead symbol, within
an equilateral triangle, is
intended to alert the user
to "dangerous voltage"
and to prevent from a risk
of electric shock.
WARNING: Do not use this STB where contact with or immersion in water is a
possibility. Do not use near flower vase, washbowls, kitchen sinks, laundry tubs,
swimming pools, etc.
WARNING: Do not put the candle or lamp stand on the cabinet; otherwise, there
is the danger of fire.
WARNING: The unit should be connected to a power supply only of the type
described in the operating instructions or as marked on the unit. If you are not
sure of the type of power supply (for example, 120 or 230 V) to your home,
consult your local dealer or local power company.
WARNING: This product install diodes. Do not open the cabinet or touch any
parts in the inner mechanism. Consult your local dealer for technical service if
the opening is required.
Note: To ensure proper use of this product, please read this User manual
carefully and retain for further reference.
Note: This product install diodes. Do not open the cabinet to avoid the unit
direct exposure to radiation.
Unit Cleaning: After the unit power is turned off, you can clean the cabinet,
panel and remote control with a soft cloth lightly moistened with a mild detergent
solution.
Warning:
To reduce the risk of
electric shock, don't open
the cabinet. Refer
servicing to qualified
personnel only.
The exclamation point
within an equilateral
triangle is intended to
alert the user to important
operating and
maintenance (servicing).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S-3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mvision S-3

  • Page 1 SAFETY PRECAUTION CAUTION: The lightning flash with Warning: The exclamation point arrowhead symbol, within To reduce the risk of within an equilateral an equilateral triangle, is electric shock, don't open triangle is intended to intended to alert the user the cabinet. Refer alert the user to important to "dangerous voltage"...
  • Page 2 Attachments: Never add any attachments and/or equipment without the manufacturer consent; as such additions may result in the risk of fire, electric shock, or other personal injury. Locating: Slots and openings in the cabinet are provided for ventilation to protect it from overheating. Do not block these openings or allow them to be blocked by placing the STB on a bed, sofa, or other similar surface, nor should it be placed over a radiator or heat register.
  • Page 3: Table Of Contents

    Contents CONTENTS 1. Remote Control & Panel Description............. 3 1.1 Front Panel Description ...................3 1.2 Rear Panel Description ..................4 1.3 Remote Control Description ................5 2. Hotkey..................... 6 2.1 Power ......................6 2.2 TXT.........................6 2.3 Mute .......................6 2.4 Number......................6 2.5 M/P (Multi-Pictures) ..................6 2.6 CH+/CH- ......................7 2.7 Vol+/Vol- ......................7 2.8 TV/RADIO.......................7...
  • Page 4 Contents 4.5 Delete All Channels ..................17 5. Installation .................... 18 5.1 Single Search....................18 5.2 Multi Search ....................20 5.3 TP Scan ......................20 5.4 Satellite List....................22 5.5 TP List ......................23 5.6 Satellite Guide....................25 5.7 Unicable Configuration...................25 6. Setup..................... 26 6.1 OSD Language....................26 6.2 TV System ....................27 6.3 Region and Time ...................28 6.4 Timer Setting....................28...
  • Page 5: Remote Control & Panel Description

    Remote Control & Panel Description 1. Remote Control & Panel Description 1.1 Front Panel Description POWER Is used to switch between the working mode and the standby mode. CH+/- To change channels or for navigating and changing values in menus. Display (4-Digit / Displays the received channel number while operating 7-Segment)
  • Page 6: Rear Panel Description

    Remote Control & Panel Description 1.2 Rear Panel Description S/PDIF Coaxial output for digital audio (AC3). VIDEO CVBS video output for TV AV in. AUDIO HiFi outputs for stereo sets IF IN Satellite input IF OUT Satellite output for cascading to other devices RS232 Serial Port allowing software upgrades TV SCART...
  • Page 7: Remote Control Description

    Remote Control & Panel Description 1.3 Remote Control Description...
  • Page 8: Hotkey

    Basic Operations 2. Hotkey 2.1 Power Press [Power] button to switch from TV mode to Standby mode In Standby mode press [Power] button again to switch back to TV mode. The last active channel will be showed. To switch off the STB complete press the main power button. 2.2 TXT Press [TXT] button in TV mode to open the teletext page.
  • Page 9: Vol+/Vol

    Basic Operations Press [▲/▼/◄/►] keys can moving highlight among each preview program, and only the highlighted preview program can play normally. When the highlight moves to the preview program that you want to play, you can press [OK] key to enter the full screen play. Press [Exit] key to go back to full screen.
  • Page 10: App

    Basic Operations 2.13 App Have no function. 2.14 Audio In TV mode, press the [Audio] button to open the Audio Mode window. Select the item you want to adjust with [▲/▼] and change the value with [Volume Up/Down]. Press [Exit] key to exit. 2.15 Information In TV mode, press [INFO] button can open information screen, in the window shows the...
  • Page 11: Sub

    Basic Operations Press EPG key will display the current channel detail information. The window is like right: Press OK in schedule and detail window can open the timer window directly. This operation add the highlighted program to a timer quickly. 2.17 Sub Press [Sub] key set up subtitle on/off.
  • Page 12: List

    Basic Operations 2.19 List In TV mode, press the [List] button to stop the display. The sound of the channel will continue. Press [Pause] again to continue the display at the actual moment. 2.20 Pup/Pdw In full screen, press [Page Up / Page Down] key can switch group directly. 2.21 Fav In TV mode press the [Favorite] button to display the Favorite Group window on...
  • Page 13: Welcome Page

    Menu Operations 3. Welcome Page When first time power on, it will show welcome page like below. This Welcome page is only for easy operation when first use, user also can setting them in main menu/Tools/Welcome Page. Press [▲/▼] key to move highlight. Press [◄/►] key to modify setup.
  • Page 14: Channel

    Menu Operations 4. Channel Press [Menu] in the TV mode to enter the main menu. Press [▼/▲] to select the menu item among Channel, lnstallation, Setup and Tools. Press [OK] to enter the selected item. In the Channel menu: Press [▼/▲] to select the wanted menu item among TV Channel List, Radio Channel List, Delete All Favorites and Delete All channels Channel.
  • Page 15: Favorite

    Menu Operations 4.1.1 Favorite Press number key [1] can open the “Favorite” window like right. You can move highlight between 8 favorite groups by press [▲/▼] key and press [OK] key to make a favorite mark in the right side of the selected favorite group.
  • Page 16: Sort

    Menu Operations After input each character, the program list on the left will search the channel according your input, and list the matched channel. Press [Exit] key can close “Find” window and you can select channel from the channels list directly. 4.1.4 Sort Press number key [4] can open the “Sort”...
  • Page 17 Menu Operations 4.1.5.1 Delete In “Edit Channel” menu, press number key [1] can make a delete mark in the right side of the highlighted channel. After save and exit “Edit Channel” menu, the marked channel will be deleted. 4.1.5.2 Skip In “Edit Channel”...
  • Page 18: Radio Channel List

    Menu Operations 4.1.5.5 Delete all In “Edit Channel” menu, press number key [5] can mark all the channel with delete mark Press number key [5] again can cancel all the delete mark. 4.2 Radio Channel List Basically, the operation of “Radio Channel List” is same as “TV Channel List”, but there is one point different: In “Radio Channel List”...
  • Page 19: Delete All Favorites

    Menu Operations 4.4 Delete All Favorites In “Delete All” item: There will display an dialogue for user to key in password. The default Password is “0000”. When you input the correct password, there will show up a warning message box to inquire you whether delete all or not.
  • Page 20: Installation

    Menu Operations 5. Installation After selecting the installation menu you can see the window like beside. In “Installation” menu; Press [CH▲/▼] to select menu items among Single Search, Multi Search, TP Scan, Satellite List, TP List , Satellite Guide Unicable Configuration.
  • Page 21 Menu Operations Notice: After choosing LNB type “Universal” you cannot modify 22K. DiSEqC1.0: Use [Vol◄/►] to switch the options or press [OK] to open the DiSEqC1.0 option list to select directly with [CH▲/▼], press [OK] to confirm it. DiSEqC1.1: Use [Vol◄/►] to switch DiSEqC1.1 option or press [OK] to enter DiSEqC1.1 option to select directly with [CH▲/▼], press [OK] to confirm it.
  • Page 22: Multi Search

    Menu Operations 5.2 Multi Search When you enter the “Multi Search” menu a window like the one beside will open. In the “Satellite” item press [Vol◄/►] to select the satellite which you want to scan or press [OK] to open the “satellite list”...
  • Page 23 Menu Operations TP Index: Use [Vol◄/►] to select the desired transponder or press [OK] to open the TP list to select directly with [CH▲/▼], press [OK] again to display the TP number where the channel can be found. Press [Red / Green / Yellow] key on the RCU for the related functions.
  • Page 24: Satellite List

    Menu Operations 22K: Use [Vol◄/►] to switch “ON” and “Off”. The 22KHz signal is used in KU universal LNBs to change between low band and high band. Notice: After choosing LNB type “Universal” you cannot modify 22K. DiSEqC1.0: Use [Vol◄/►] to switch the options or press [OK] to open the DiSEqC1.0 option list to select directly with [CH▲/▼], press [OK] to confirm it.
  • Page 25: Tp List

    Menu Operations Press [Red] button to enter edit satellite menu. You can edit the satellite’s name and its longitude. Press [Green] button to open the “Add satellite” window. After pressing [Yellow] button you will be asked “Are you sure to delete?”. Select “OK”...
  • Page 26 Menu Operations Press [Red] button to open the “Edit TP” menu. Here you can edit the transponder’s data. Press [Green] button to open the “Add TP” menu. Here you can add a new TP and setup its parameters. Press [Yellow] button will open a dialog box asking you to confirm the deletion of the current TP.
  • Page 27: Satellite Guide

    Menu Operations 5.6 Satellite Guide When you enter “Satellite Guide” menu, you will see the screen like beside: Here you can enter your local longitude and latitude and the satellite’s longitude. The receiver calculates antenna’s orientation and elevation to point your antenna to the selected satellite.
  • Page 28: Setup

    Menu Operations 6. Setup When you enter to “System Setup” menu, you will see the screen like right: In “System Setup” menu: Press [▼/▲] key to select menu pages among OSD Language, TV System, Start up Service, Region and Time, Timer Setting, OSD Setting, Parental Lock and RCU Position.
  • Page 29: Tv System

    Menu Operations Second Audio: If the channel has no correspond audio with “First Audio” but have corresponded audio with “Second Audio”, system will play the second audio language as default. If no audio language corresponds with the “Second Audio”, then the default language of current channel will be played automatically.
  • Page 30: Region And Time

    Menu Operations 6.3 Region and Time When you enter to “Region and Time” menu, you will see window like right: Region is used for selecting the country which you are in. You can press [◄/►] key to select each mode circularly. GMT Usage: This item is use for open the usage of GMT.
  • Page 31 Menu Operations Current time information will display on the first column; if the current time is incorrect, please modify the time information in “Time” item. Timer Number: You can press [◄/►] keys to set Timer number, and there are 8 timers in total. Timer Mode: There are several modes for Timer to setting, include Off, Once, Daily, Weekly, Monthly and Yearly.
  • Page 32 Menu Operations is in standby mode or in playing mode, the system will automatically pop a reminding message. Ø The message will always display on the screen, you can press [Exit] key to close it. Press [Exit] key to draw back from “Program Timer” menu. Sleep Timer When you enter “Sleep Timer”, you will see the window like right:...
  • Page 33: Osd Setting

    Menu Operations 6.5 OSD Setting When you enter to “OSD Setting” menu, you will see a screen like right: Subtitle Display: You can press [◄/►] key to select “On” or “Off”. If the current channel has subtitle information, it will be showed up while this function is “On”.
  • Page 34 Menu Operations In “Parental Lock” function, press [OK] key, there will pop an dialogue for you to input the password. The default password is “0000”. When you input the correct password, you will see a screen like right: Menu Lock determining that when user wish to enter “Installation”...
  • Page 35: Tools

    Technical specification 7. Tools When you enter to “Tools” menu, you will see a screen like right: In “Tools” menu: Press [▼/▲] key to select menu pages among Information, Game, Load Factory Default, Software Upgrade and Welcome Page. Press [▼/▲] key to select menu items among each items.
  • Page 36: Load Factory Default

    Technical specification [▼] — Faster drop Ø Ø [OK] — Pause/Play the game Ø [Exit] — Quit game and draw back to “Tetris” menu. Snake ² Moving highlight to “Setup” and press [◄/►] key to select the game level (speed). ²...
  • Page 37: Software Upgrade

    Technical specification In step 1 and step 2, press [Exit] key can draw back from this item and without saving. 7.4 Software Upgrade We offer the functions for user to connecting receiver (Master) to the other receiver (Slave) via serial interface to upgrade software code and program list.
  • Page 38: Technical Specification

    Technical specification 8. Technical specification VIDEO Decoding MPEG-2 & MEPG-1 compatible Bit rate Max 15Mbps Output PAL/NTSC Aspect ratio 4:3, 16:9, Auto Active pixel 720x480 @ 30fps; 720x576 @ 25fps Output connector RCA, SCART AUDIO Decoding MPEG-2/MPEG-1 layer I & II Mode Mono, Dual, Stereo, Joint stereo Bit rate...
  • Page 39 Technical specification LNB CONTROL Power supply 13/18V (500mA max) with short circuit protection Polarized control 13/18V polarization (vertical/horizontal) DiSEqC control DiSEqC1.0, DiSEqC1.1 and DiSEqC1.2 RF MODULATOR Input IEC 169-24 Male x 1 Output IEC 169-24 Female x 1 Band TV Standard PAL BG/I/DK, NTSC M Output Channel 21~69(PAL), 14~83(NTSC)
