- Page 1 Cityline 100 IDC Lamp post Door Mounted Charge Point Instructions Revision 1.2, April 2021 Copyright © 2021 CityEV Limited All Rights Reserved. All trademarks are owned CityEV Limited...
- Page 2 Cityline 100 IDC Lamp Column Door Indicator LED Functions The Cityline 100 IDC uses 2 tricolour LEDS to indicate the charge point status The LED functions are set out in the table below. System Status LED (1) Chargepoint not powered up System OK.
- Page 3 Cityline 100 IDC User Operation Charging Status (EV) LED (2) EV not connected Authorised to charge 1 flash every 4 seconds EV Connected Charging in progress EV Charged EV Fault Earth probe fault detected. Not available to charge LED key:...
- Page 4 Cityline 100 IDC User Operation To charge your vehicle: 1. Ensure that the charge point is ready and available for changing. This is indicated by a GREEN system check LED. 2. Connect the EV to using the appropriate cable to the type 2 EV connection socket located on the front of the unit.
