- Page 1 INSTRUCTION MANUAL SPYRON High Performance Night Vision Monocular SPYRON Instruction Manual 2021 The world belongs to those who can see the beauty at night...
- Page 2 ADVISORY OVERVIEW The following description categorizes the level of risk associated with each cautionary statement displayed throughout the manual. WARNING HIGHLIGHTS An operation or procedure which, if not strictly observed, could result in injury or death of personnel. CAUTION HIGHLIGHTS An operation or procedure which, if not strictly observed, could result in damage or destruction of equipment or loss of mission effectiveness.
-
Page 3: Table Of Contents
TABLE OF CONTENTS CHAPTER 1: GENERAL INFORMATION Introduction Equipment Description Standard Kit Parts List Standard Kit Parts Illustration System Performance and Data CHAPTER 2: PREPARATION FOR USE Introduction Battery Precautions Battery Installation Eyecup Installation Sacrificial Window Installation J-Arm Mount Installation Installation of Weapon Mount (optional) CHAPTER 3: OPERATING INSTRUCTIONS Introduction... - Page 4 CHAPTER 4: MAINTENANCE INSTRUCTIONS Introduction Deactivation Battery Removal Cleaning the SPYRON Cleaning the Optics Checking for Damage and Corrosion CHAPTER 5: TROUBLESHOOTING Troubleshooting Procedures APPENDIX A: SPARE AND REPAIR PARTS LIST APPENDIX B: WARRANTY INFORMATION APPENDIX C: DECLARATION OF CONFORMITY SPYRON Instruction Manual 2021...
-
Page 5: Chapter 1: General Information
CHAPTER 1: GENERAL INFORMATION Introduction This manual provides operation and field level maintenance instructions for the SPYRON. It also provides specifications and data on the performance of the monocular. To ensure the safety of the operator and the correct operation of the monocular it is recommended that this manual is read carefully in its entirety before any deployment or field application. -
Page 6: Standard Kit Parts List
The standard SPYRON kit comes with the items listed here under: Item Description Quantity Monocular Assembly AA Alkaline Battery Sacrificial Lens J-Arm Operator Manual Digital Hard Carrying Case Table 1-1 Standard Kit Parts List Standard kit parts illustration SPYRON Instruction Manual 2021... -
Page 7: System Performance And Data
System performance and data: The chart below lists the technical specifications and data of the SPYRON system. The data contained herein is subject to change without notice. ITEM LIMITS Electrical Data Power Source Battery (1.5V DC max.) Battery Requirements 1 AA Alkaline or 1 AA Lithium L91 Battery Life (AA Alkaline) 40 hrs @ 21°C (70°F) -
Page 8: Introduction
Introduction This section contains instructions for installing and attaching various components and accessories to the SPYRON for operation under normal conditions. Battery precautions WARNING Do not mix alkaline and lithium batteries. Do not mix old and new batteries. Do not mix brands of batteries. Do not mix disposable and rechargeable batteries. Failure to follow these instructions could result in death, injury or imposition of long- term health hazards. -
Page 9: Eyecup Installation
Install one Alkaline AA battery as follows: Remove the battery cap by turning it counter-clockwise. Check to ensure the O-ring is present. Observe polarity as indicated on the outside of the battery compartment. Insert the Alkaline AA battery into the battery compartment, minus end first. Replace battery cap by pushing and turning it clockwise. -
Page 10: Sacrificial Window Installation
Perform the following procedure to install the sacrificial window onto the objective lens assembly. CAUTION If adverse operating conditions (blowing dust or sand) are expected to exist, attach the sacrificial window to protect the objective lens from scratches or other damage. If the objective lens cap is in place, remove it. -
Page 11: Installation Of Weapon Mount (Optional)
Perform the following procedure to install the weapon mount. Figure 2-3 Weapon Mount Adapter Installation CAUTION The SPYRON is not a weapon sight. However, it can be used in conjunction with a collimated dot sight or laser aiming device. NOTE It is recommended to replace the eyecup with the shuttered eye guard during weapon mounted use. -
Page 12: Chapter 3: Operating Instructions
A ratchet in the weapon mount prevents over tightening of the clamp. Turn until the knob clicks. Check the position of the monocular by holding the weapon in the normal firing position. Adjust the fore/aft position of the monocular as necessary by loosening the clamping knob and repositioning the weapon mount on the weapon’s mounting rail. -
Page 13: Introduction
Introduction This chapter contains instructions for the safe operation of the SPYRON under normal circumstances and environments. Controls and indicators The SPYRON is designed to adjust for different users and corrects for most differences in eyesight. CAUTION The SPYRON requires some ambient (moonlight, starlight, or artificial light, etc.) The level of performance depends on the light level. - Page 14 Control and indicator Function Power Switch Controls monocular and IR source, ON or OFF. RESET/OFF Same as system OFF. OFF also resets monocular after high light cut- off. ON activates the monocular. IR/PULL Pull and turn the knob clockwise from the ON position to continuously activate the IR source.
-
Page 15: Hand-Held Operation
Hand-held operation CAUTION Operate the SPYRON only in dark conditions or use the objective lens cap to cover the objective lens for daylight conditions. NOTE When using the SPYRON without a mounting device, make sure to place the neck cord around your neck. Ensure that the battery is installed correctly. -
Page 16: Using The Gain Control
For momentary IR use, turn the power switch knob clockwise (without pulling) past the ON position. Observe that a red light appears in the eyepiece. When the switch knob is released, the knob will return to the ON position and the IR source will be powered OFF. -
Page 17: Sand Operation In Rainy Or Humid Conditions
Ensure that the sacrificial window is in place. Avoid pointing the monocular into the wind unless necessary for operation. Keep the carrying case closed unless removing or replacing items. Ensure that all dust and sand is removed from the SPYRON and carrying case after operation. - Page 18 NOTE Prior to placing the SPYRON into the hard case, ensure the SPYRON hard case is free of dirt, dust, and moisture. Place the monocular, accessories and cleaning supplies back into the hard case. It is best to place the items in their original locations to prevent any possible damage to the unit and/or accessories.
-
Page 19: Chapter 4: Maintenance Instructions
CHAPTER 4: MAINTENANCE INSTRUCTIONS Introduction The SPYRON is designed to be used in diverse environments and rugged conditions. It is recommended that regular and simple maintenance be performed for optimal system performance. CAUTION The SPYRON is a precision electro-optical instrument and must be handled carefully. -
Page 20: Checking For Damage And Corrosion
each lens tissue after one use to avoid transferring grit or foreign matter onto the lens surfaces. If the lens remains dirty use a cotton swab lightly moistened with lens cleaning fluid to remove the foreign matter from the lens. Dry with a clean unused lens tissue. Checking for damage and corrosion As a general guideline, conduct an inspection of the SPYRON, accessories, and the case after every use. -
Page 21: Chapter 5: Troubleshooting
CHAPTER 5: TROUBLESHOOTING Troubleshooting procedures Table 5-1 lists common malfunctions that may occur with the equipment. Perform the tests, inspections and corrective actions in the order they appear in the table. This table cannot list all the malfunctions that may occur, all the tests and inspections needed to find the fault, or all the corrective actions needed to correct the fault. - Page 22 Diopter adjustment Check to see if the diopter If damaged, refer to higher level of cannot be made. adjustment is bent or maintenance. broken. Monocular does not Visual. If damaged, refer to higher level of cut off when maintenance. exposed to high Perform the following test light.
-
Page 23: Appendix B: Warranty Information
APPENDIX A: REPAIR & SPARES This section provides information needed to identify, contact and order spare and/or repair parts for the SPYRON. To order spare or repair parts for the SPYRON or any of your night vision products contact your local distributor. You can find his contact data on www.spyronnv.com APPENDIX B: WARRANTY INFORMATION The SPYRON monocular is warranted to be free from defects in materials or workmanship for 2 years from the purchase date. - Page 24 installed, used, repaired or are modified other than pursuant to the applicable ACTinBlack Europe S.A.R.L. maintained or instructions or approval, or have been subjected to any other kind of misuse or detrimental exposure, or have been involved in an accident. The warranty terms may be modified only with written agreement.
-
Page 25: Appendix C: Declaration Of Conformity
APPENDIX C Declaration of Conformity ACTinBlack Europe S.A.R.L. 12 rue de l’Industrie, L-3895 Foetz, Grand Duchy of Luxembourg declare under our sole responsibility that our product Product name: SPYRON Trade name: ACTinBlack® to which this declaration relates is in conformity with the appropriate standards following the provisions of EMC Directive 2014/30/EU RoHS 2 Directive (EU) 2017/2102...
