Install the AWG-HD into a system

Install the AWG-HD into a system
2
Environmental
specification Description
Power 100-240 V, 50/60 Hz, 120 W
Temperature 10 -30 Deg. C (operating)
Humidity
Operating 5% to 90% relative humidity (% RH) at up to +30° C, non-condensing
Non-operating 5% to 90% relative humidity (% RH) at up to +30° C, non-condensing
5% to 45% RH above +30° C up to +50° C, non-condensing
Altitude 3000 m
WARNING.
To reduce the risk of fire and shock, ensure that the mains power
supply voltage fluctuations do not exceed 10% of the operating voltage range.
The AWG-HD is part of a system of Tektronix instruments that allows you to
perform HDMI testing. The following equipment makes up the system that the
AWG-HD instrument will be inserted into.
Table 1: System equipment
Instrument Quantity
AWG-HD 1
AWGSYNC01 1
AWG70001 4
1
DPO70000SX
Series
DUT As
required
HD-EDID–TEMSS 1
HDA2.1-TPA-P 1
HDA2.1-TPA-R 1
Description
HDMI fixture for sink (Rx) testing with programmable delay
and amplitude.
Synchronization hub to synchronize signal output from two to
eight channels on two to four AWG70000 series instruments.
Arbitrary waveform generator. 50 GS/s.
Digital Phosphor Oscilloscope.
Customer device under test.
HDMI 2.1 EDID Emulator 600-1121-001 with Sink/Source
License
HDMI 2.1 Plug Test Adapter
HDMI 2.1 Receptacle Test Adapter
