Introduction

Related documents
available on www.tek.com
AWG-HD connectors and environmental specifications
AWG-HD Installation and Safety Instructions
The Tektronix AWG-HD is an HDMI fixture for sink (Rx) testing with
programmable delay and amplitude. This document provides the following
information:
Connectors and environmental specifications
How to install the AWG-HD into a system
Safety and compliance information for the AWG-HD product
AWG-HD Programmer Manual
TekExpress® FRL Solution Application Help (Available from the
TekScope menu in the TekExpress application and as downloadable PDF
at www.tek.com.)
AWGSYNC01 Safety and Installation Manual
AWG70000 Series Help
AWG-HD Specifications and Performance Verification Technical Reference
TekExpress® eARC Solution Application Help (Available from the
TekScope menu in the TekExpress application and as downloadable PDF
at www.tek.com.)
Front panel
connector Quantity
SMA. 50 Ω
16
Rear panel
connector Description
Power 100-240 V, 50/60 Hz, 120 W
Ethernet 10/100 Mbps, CAT5e
Description
There are 4 identical channel connectors.
Each channel has 2 IN connectors and
2 OUT connectors.
1
