Epson S1C31D50 Getting Started

Sound mcu
Hide thumbs

Advertisement

Quick Links

Sound MCU: S1C31D50
Evaluation Board
"
Getting Started"
*The information in this file is subject to change without notice.
Rev.1.0.0
© Seiko Epson Corporation 2018. All rights reserved.

Advertisement

loading

  Also See for Epson S1C31D50

  Related Manuals for Epson S1C31D50

  Summary of Contents for Epson S1C31D50

  • Page 1 Sound MCU: S1C31D50 Evaluation Board “ Getting Started” *The information in this file is subject to change without notice. Rev.1.0.0 © Seiko Epson Corporation 2018. All rights reserved.
  • Page 2 Preparation Please prepare following before start. ① S1C31D50 Evaluation Board (from EPSON) ② Speaker Cable (from EPSON) ③ Speaker ④ USB Micro–B Cable ⑤ USB Power(USB battery, PC etc) ⑤ ① ③ ② ④...
  • Page 3 Pre-install DEMO...
  • Page 4: Board Setting

    Board Setting • Please set the board as following.(Default) speaker connect all...
  • Page 5 Board Connect ① Connect Speaker cable & Speaker ② Connect USB and Supply power, LED shows power supply turns on ③ After pressing reset button, LED shows Demo Ready turns on LED(power supply) Reset Button ② ① ③ ① LED(Demo Ready)
  • Page 6 Setup Demo ① Please set Language you want to show. ② Push “Reset” button..S1C31D50 reads DIP SW setting ② Reset button ※1 ① ※1: Push reset button every time after change the language...
  • Page 7 Japanese Pre-Install Demo Contents CH0 ... voice CH1 ... music 「あと5分でお風呂が沸きます。」 ♪Amazing Grace 「お風呂が沸きました。」 ♪Canon 「給湯温度が/30℃に設定されました。」 ♪ 「給湯温度が/31℃に設定されました。」 ♪ 「給湯温度が/32℃に設定されました。」 ♪ 「給湯温度が/33℃に設定されました。」 ♪ 「給湯温度が/34℃に設定されました。」 ♪ ♪ CH0:“Voice Speed” can be changed Note: Demo Contents might be changed without notification. “/” can achieve to share a common phrase automatically (Please see EPSER2 Manual) Japanese...
  • Page 8 English Pre-Install Demo Contents CH0 ... voice CH1 ... music The coffee is ready, enjoy! ♪Amazing Grace It's ready, enjoy the dinner. ♪Canon The bath is ready. ♪ The temperature is set at 38 //degree. ♪ The temperature is set at 39 //degree. ♪ The temperature is set at 40 //degree.
  • Page 9 Chinese Pre-Install Demo Contents CH0 ... voice CH1 ... music 我準備好洗澡了 ♪Amazing Grace 设定的温度是/30度 ♪Canon 设定的温度是/31度 ♪ 设定的温度是/32度 ♪ 设定的温度是/33度 ♪ 设定的温度是/34度 ♪ 设定的温度是/35度 ♪ ♪ CH0:“Voice Speed” can be changed Note: Demo Contents might be changed without notification. “/” can achieve to share a common phrase automatically (Please see EPSER2 Manual) Chinese...
  • Page 10 Korean Pre-Install Demo Contents CH0 ... voice CH1 ... music 온도가 38도로 /설정되었습니다. ♪Amazing Grace 온도가 39도로 /설정되었습니다. ♪Canon 온도가 40도로 /설정되었습니다. ♪ 온도가 41도로 /설정되었습니다. ♪ 온도가 42도로 /설정되었습니다. ♪ 목욕준비가 완료되었습니다. ♪ 건전지를 교체해 주세요. ♪ ♪ CH0:“Voice Speed” can be changed Note: Demo Contents might be changed without notification.
  • Page 11 Fire Alarm 4 Language Demo Contents CH0 ... voice CH1 ... music ♪(Sweep), ♪(Sweep), 煙が感知されました。 A Smoke is detected 检测到烟雾。 연기가 감지되었습니다. Note: Demo Contents might be changed without notification. FireAlarm...
  • Page 12 Start pre-install Demo ① Please push Reset button Reset Button ② Please start the demo(see following) Ex1) ① Push① Reset - Voice Speed Normal(100%) LED turns on Push③ Background music start - CH1 LED turns on Push② Voice start (mixed with music) - CH0 LED turns on Ex2) Push①...
  • Page 13 Thank you.
