Technical Specifications - Johnson Controls VFD66 Series Product/Technical Bulletin

Technical Specifications

Product
Input Power
Output Voltage/Frequency
Pulse Width Modulation
Carrier Frequency
Duty
Overload Capacity
Maximum Output Ampere
Limit
Acceleration/Deceleration
Start/Stop
Lead Length
Ambient Temperature
Altitude
Relative Humidity
Available Enclosures
Agency Listings
Emissions Compliance
Input Devices
Dimensions (H x W x D)
Shipping Weight
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these
specifications, consult Johnson Controls/PENN Refrigeration Application Engineering at 1-800-275-5676. Johnson Controls, Inc. shall not be
liable for damages resulting from misapplication or misuse of its products.
VFD66 Series Condenser Fan Speed Controls
208/230 VAC or 460 VAC @ 60 Hz (230 VAC or 400 VAC @ 50 Hz)
208/230 VAC or 460 VAC @ 60 Hz (230 VAC or 400 VAC @ 50 Hz)
2.3 kHz
Continuous
110% of ampere rating for 1 minute
110% of ampere rating, non-adjustable
Selectable - 5 seconds or 30 seconds
Line start with single auto-restart 30 seconds after fault
Maximum lead length between motor and VFD66 control is 50 ft (15 m).
Storage: -40 to 158°F (-40 to 70°C) Operating: -40 to 140°F (-40 to 60°C) – See De-Rating
the VFD66 Control for
High Temperatures and High Altitudes.
3,300 ft (1,000 m) maximum without de-rating maximum output amperes – See De-Rating
the VFD66 Control for
High Temperatures and High Altitudes.
0 to 95% noncondensing (storage and operating)
NEMA 1, UL Type 1 convection cooled (Some are fan cooled.)
Enclosures have three 1/2-in. trade size conduit openings.
UL Listed, File E184521, Guides NMMS (UL 508C) and NMMS7 (CSA C22.2 No. 14).
FCC (US), DOC (Canada), based on EU testing with Emissions Compliance items installed,
shown in Figure 8.
EU Directive Compliance (CE mark); 72/23/EEC (Low Voltage Directive) and 89/336/EEC
(EMC Directive) compliance with Emissions Compliance items installed, shown in Figure 8.
Johnson Controls/PENN (A350P, P35, P352P, P499, Performer Rack Controllers)
Johnson Controls Metasys® system (AHU, DME, DX9100, UNT, VAV)
Also works with rack controllers, electronic pressure transducers, and other 0-5 VDC or
0-10 VDC input signal devices made by various manufacturers.
See Figure 2.
NEMA 1 Enclosure models – 5.6 lb (2.5 kg)
NEMA 1 Enlcosure models with Optional Alarm Board – 5.8 lb (2.6 kg)
Metasys® and Johnson Controls® are registered trademarks of Johnson Controls, Inc.
All other marks herein are the marks of their respective owners. © 2010 Johnson Controls, Inc.
VFD66 Series Condenser Fan Speed Controls Product/Technical Bulletin
Building Efficiency
507 E. Michigan Street, Milwaukee, WI 53202
17
