Mechanics Helper – Rear wheel Removal/Installation
________________________________________________
Rear Wheel Removal/Installation
Basic description.
The IQ 450 electric scooter uses inflatable tires for a smooth and comfortable ride. The
drive belt is easily installed and never needs tensioning once installed. These belts do
not stretch and will break if over tensioned. To insure good service life from belts and
tires keep the grooves in belt pulleys free of gravel and small rocks. Be careful of thorns,
which will puncture tires and keep tire pressure relatively high at 45 psi. To avoid flats
on future rides consider thicker thorn proof tubes available from Vego.com
Procedure
1. Turn scooter power off.
2. Remove battery
3. Remove the six screws and seat tube clamp, which affix the body to the chassis.
4. Remove the body.
5. Loosen and remove brake arm bolt using a 4mm allen wrench and an 10mm wrench.
Brake Arm Bolt
Axel Nuts
Axel Tensioner
Nuts
Advertisement
Table of Contents
Related Manuals for Vego IQ 450
Summary of Contents for Vego IQ 450
- Page 1 Rear Wheel Removal/Installation Basic description. The IQ 450 electric scooter uses inflatable tires for a smooth and comfortable ride. The drive belt is easily installed and never needs tensioning once installed. These belts do not stretch and will break if over tensioned. To insure good service life from belts and tires keep the grooves in belt pulleys free of gravel and small rocks.
- Page 2 6. Loosen the axle tensioner nuts. 7. Loosen the axle nuts. 8. Move rear wheel forward to detention drive belt. 9. Slide belt first off rear pulley. 10. The wheel is now ready to remove, be cautious because the wheel is still connected to the scooter by the brake cable.
