Summary of Contents for Vego IQ 450
-
Page 1: Table Of Contents
TABLE OF CONTENTS Safety Information Table of Contents Notice Scooter Diagram Setup Guide Charging Instructions Pre-Ride Checklist Trouble Shooting 12-13 Specifications Maintenance Schedule 15-18 Limited Warranty 19-22... -
Page 2: Notice
NOTICE YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE FOR ACCIDENTS INVOLVING THE USE OF THIS SCOOTER. TO DETERMINE IF COVERAGE IS PROVIDED, YOU SHOULD CONTACT YOUR INSURANCE COMPANY. -
Page 3: Scooter Diagram
SCOOTER DIAGRAM • Seat • Throttle • Seat Post • Seat Height • Handle Bar Quick Adjustment Release Bolt • Seat Tube • Steer Tube • Circuit • Black Locking Breaker Lever • Quick • Charge Jack Release Lever... -
Page 4: Setup Guide
SETUP GUIDE Unfold Scooter (a) Loosen quick release l e v e r. (b) Pull the gray locking l e v e r upwards. (c) Unfold the scooter. Install Handlebars CAUTION: If you are not familiar with bicy - cle assembly tech - niques please bring your scooter to a qualified... - Page 5 SETUP GUIDE Adjust Handlebar Height P r e s s the small gold button while inserting the handlebar into the steer tube. Make sure the gold button is locked into one of the four pre- set height set- t i n g s . Tighten Handlebars Tighten the quick release lever to lock the handlebars in place.
- Page 6 SETUP GUIDE Install Seat Fully insert the seat assembly and tighten the seat tube quick release lever at the base of the seat tube. Adjust seat height with supplied allen wrench. Do not adjust seat height at the base of the seat tube. Caution: The seat tube must be fully inserted into the scooter frame.
- Page 7 In order to have a safe ride and abide by federal law you must wear a helmet every time you ride your Vego scooter. Please wear your helmet every time you ride! Turn Power On Turn the scooter power on using the key.
- Page 8 CHARGING 1. Plug your smart charger into a regular household outlet. Note: Your smart charger is equipped with a multivolt feature. This allows you to plug the charger into an outlet in a foreign country or any power source from 100 to 240volts AC. 2.
-
Page 9: Pre-Ride Checklist
PRE-RIDE CHECKLIST Warning : If you do not perform these simple saftey checks before each ride, you risk serious injury due to improperly maintained equipment. •Read and understand all safety instructions. •Check all three quick release levers for tightness. a.Handlebar quick release lever b.Seat tube quick release lever c. -
Page 10: Trouble Shooting
TROUBLE SHOOTING Problem Symptom Solution •Charge light does not •Green Power light illu- •Battery charge jack is come on, scooter will nates when charger is not properly connected not recharge. plugged into household to the charger. See outlet but red charge Charging section of light does not illumi- this manual for... - Page 11 TROUBLE SHOOTING Problem Symptom Solution •Charge light does not •No red power light •Try a different out- come on. Scooter will not comes on when the let. If there is still no recharge. charger is plugged into a power light the working household charger must be power outlet.
-
Page 12: Specifications
SPECIFICATIONS Batteries: Sealed lead acid. Two 12volt 12amp hour cells connected in series. Motor: Rare earth magnet direct current Motor. 350 watts. Frame: Tig welded steel box frame. Body: Injection molded ABS plastic with locking battery door. Drive: Toothed drive belt and freewheel. Throttle: Quarter length twist throttle. -
Page 13: Maintenance Schedule
MAINTENANCE SCHEDULE Below are tips to help keep your scooter running well. This schedule is calculated based on a 1 mile daily commute ride. Item Inspection Instructions •Tires • Every 30 days check the side- walls and tread for damage. Tires will need replacement about once a year. - Page 14 MAINTENANCE SCHEDULE Inspection Instructions Item •Bearings • Vego scooters use all sealed bearings. The only bearings that require adjustment are the head- set. Adjust the headset only if it feels loose. •Brakes •Once a year check the brake shoes for wear. The brake system...
- Page 15 MAINTENANCE SCHEDULE Item Inspection Instructions •Batteries • Immediately after every ride charge your batteries. The batter- ies are rated at 750 charge cycles. That means if you ride everyday you will need a new battery pack after about two years. The best method to ensure good battery life is to charge the batteries to full after every ride.
- Page 16 MAINTENANCE SCHEDULE Item Inspection Instructions • Every 6 months check the front •Front Fender fender for tightness and align- ment. Often a loose fender will make a buzz or rattle sound. If the fender is misaligned, straighten it using your hands while peering straight down on the front tire from above.
-
Page 17: Limited Warranty
If any of the foregoing is determined by Vego to have been defective during the one (1) year period, as your sole remedy, Vego will, at its option, either repaint the product (if applicable) or repair or replace a component using a new or remanufactured component. - Page 18 LIMITED WARRANTY WARRANTY CONDITIONS AND EXCLUSIONS: This limit- ed warranty is conditioned upon the Product being operated under nor- mal conditions and being properly used and maintained. WARRANTY CLAIMS MUST BE MADE DURING THE APPLICABLE WARRAN- TY PERIOD. This limited warranty does not cover: •...
- Page 19 • Damage caused by use of a charger not supplied by Vego. • Damage occuring during transportation of the product (such claims are the sole resposibility of the shipper).
- Page 20 LIMITED WARRANTY DISCLAIMER OF WARRANTIES. EXCEPT FOR THE FOREGOING LIMITED WARRANTY, VEGO MAKES NO OTHER EXPRESS OR IMPLIED WARRANTIES TO THE EXTENT PER- MITTED BY LAW SPECIFICALLY DISCLAIMS AND EXCLUDES ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITA- TION TO THE IMPLIED WARRANTIES OF NONINFRINGEMENT OF THIRD PARTY RIGHTS, MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
