Allied Telesis AT-A45/SC-SM15 Datasheet

Datasheet | Expansion Modules
AT -A45/XX, AT -A46, AT -A47 & AT -STACKM
Expansion Modules for AT-8000, AT-8500 and AT-8600 Series Switches
AT -A45/SC
Single port 100FX module w/SC connectors
AT -A45/MT
Single port 100FX module w/MT connectors
AT -A45/SC-SM15
100BaseFX singlemode module, 15km
AT -A46
Single-port 10/100/1000T module
AT -A47
Unpopulated GBIC module
AT -STACKM
Stacking kit
AT -A45/xx Series Expansion Module
The AT-A45/xx series of expansion modules
provide optional uplink ports for AT-8000
Series, AT-8500 Series and AT-8600 series Fast
Ethernet switches. Hot-swappable, they plug
into the expansion slot(s) on the front of the
switches without having to power OFF the
switch.Their modularity offers flexibility in build-
ing or expanding your network. A maximum of
two expansion modules can be installed in a
switch, depending on the number of slots on
the model.
Expansion Modules
Expansion Module Port Type
AT-A45/SC 100base-FX
AT-A45/MT 100Base-FX
AT-A45/SC-SM15 100Base-FX
AT-A46 10/100/1000T
AT-A47 1000Base-X
AT-STACKM N/A
Allied Telesis Allied Telesis
The AT-A45/SC-SM15 singlemode transceiver
is a high-performance module for bi-directional
serial optical data communications, operating at
a nominal wavelength of 1310nm.The transmitter
section uses a multiple quantum well laser and is
class 1 laser-compliant according to international
Safety Standard IEC-825.The receiver section
uses a planar InGaAs PIN photodiode for low
dark current and excellent responsivity.
The AT-A45/SC and AT-A45/MT multimode
transceivers are ideal for the 2km multimode
fiber backbone.The transmitter section utilizes
1300nm Surface Emitting InGaAsP LEDs.
AT -STACKM Expansion Module
The optional AT-STACKM module provides
a Gigabit Ethernet connection between compati-
ble AT-8000 Series Fast Ethernet switches for
improved network performance.The AT-STACKM
modules can be installed without powering off
the switches. A maximum of two stack modules
can be installed in a switch.
Note: The GBIC module for the AT-A47 expansion
module is sold separately. Refer to the GBIC module
Installation Guide or contact your Allied Telesis sales
representative for additional information on available
GBIC modules.
Connector Type Cable Type
SC 50/125 or 62.5/125 µm
multimode fiber
MT-RJ 50/125 or 62.5/125 µm
multimode fiber
SC 9/125 µm singlemode fiber 15 km (9.3mi)
RJ-45 10base-T: CAT 3 or better;
100/1000Base-T: CAT 5 or
better
Varies by Varies by
GBIC module GBIC module
N/A Hyper Speed Serial
Data Cable (HSSDC)
Key Features
•
•
•
•
•
Max.Cable Length
Half-Duplex: 412m (1,360ft)
Full-duplex: 2km (6600 ft)
Half-Duplex: 412m (1,360ft)
Full-duplex: 2km (6600 ft)
100m (328 ft)
Varies by
GBIC module
.5 meter
Fully compliant with 100 base-FX/IEEE
802.3u optical performance requirements
Industry-standard 1 x 9 Footprint
Wave solder compatible
Aqueous wash process compatible
Manufactured in an ISO 9002 certified facility
