OPERATING INSTRUCTIONS AND REPLACEMENT PARTS
Models: SVF-8AC, SVF-6ACAN, SVF-15ACAN, SVF-25ACAN
SVF-8DC, SVF-6DCAN, SVF-15DCAN, SVF-25DCAN
WArNiNG
this manual must be read carefully and followed by all persons who have or will have the responsibility
for using or servicing this equipment. this equipment will perform as designed only if used according
to the instructions. otherwise it could fail to perform as designed, causing personal injury or death.
Air SySteMS iNterNAtioNAl, iNC.
829 Juniper Crescent, Chesapeake, Va, 23320
Telephone (757) 424-3967
Toll Free 1-800-866-8100
Fax No. (757) 424-5348
www.airsystems.com.
e-mail: sales@airsystems.com
Advertisement
Table of Contents
Related Manuals for AIR SYSTEMS INTERNATIONAL SVF-8AC
Summary of Contents for AIR SYSTEMS INTERNATIONAL SVF-8AC
- Page 1 OPERATING INSTRUCTIONS AND REPLACEMENT PARTS Models: SVF-8AC, SVF-6ACAN, SVF-15ACAN, SVF-25ACAN SVF-8DC, SVF-6DCAN, SVF-15DCAN, SVF-25DCAN WArNiNG this manual must be read carefully and followed by all persons who have or will have the responsibility for using or servicing this equipment. this equipment will perform as designed only if used according to the instructions.
- Page 2 Attach all grounding wires and assure a complete circuit to the blower or fan in order to remove static charges. The Saddle Vent® is a registered trademark of Air Systems International, Inc. The Conductive Saddle Vent® is covered by U.S. and Foreign Patents...
- Page 3 SAFETY PRECAUTIONS reAD AND FolloW All iNStrUCtioNS BeloW All ventilation procedures should comply with federal, state, and local regulations. Air quality should be tested prior to ventilating a confi ned space. A purge chart is provided on our website, www.airsystems.com, help assist in estimating the approximate time needed to ventilate confi ned spaces.
- Page 4 WArNiNG: Vehicle electrical systems must be able to handle 15 amp service or electrical damage may occur. AC versions require 115 VAC/60Hz (SVF-8AC), 15 amp service or 220 VAC/50Hz (SVF-8AC50). Note: If an extension cord is required, the minimum recommended size is 14 AWG up to 25 ft.
- Page 5 1996 NEC Code requirement: Section 305-6. Order P/N ELCB013. iteM # DeSCriPtioN PArt # INTAKE GUARD MGDAXFAN1 SV-FAN-8MM HANDLE HDWR056 115VAC 60Hz ELECTRIC MOTOR (SVF-8AC) SVF-8AC-MA 220VAC 50Hz ELECTRIC MOTOR (SVF-8AC50) MTR043CN50 DISCHARGE GUARD MGDAXFAN2 ON/OFF SWITCH ELSW038R POWER CORD...
- Page 6 System Components - DC Voltage Fans iteM # DeSCriPtioN PArt # INTAKE GUARD MGDAXFAN1 SV-FAN-8MM HANDLE HDWR056 12 VDC ELECTRIC MOTOR WITH INLINE FUSE/FUSE HOLDER MTR044CN 20A 32 VDC IN-LINE FUSE ELF022 DISCHARGE GUARD MGDAXFAN2 ON/OFF SWITCH ELSW038R POWER CORD ELCB045 RED BATTERY CLAMP ELA083R...
- Page 7 Check and replace. Use only a 20A/32 VDC slow Blown fuse (DC version only) blow fuse. Fan will not run Ensure proper connection from battery clips to bat- SVF-8DC only Battery connection tery terminal posts. On battery pack units, recharge battery. Wiring Schematic - SVF-8AC-MA...
- Page 8 The purchaser shall be solely responsible for compliance with all applicable Federal, State and Local OSHA and/or MSHA requirements. Although Air Systems International believes that its products, if operated and maintained as shipped from the factory and in accordance with our “operations manual”, conform to OSHA and/or MSHA requirements, there are no implied or expressed warranties of such compliance extending beyond the limited warranty described herein.
