Crest Audio CSBM Manual

CSBM
TV Sound Bar Mount
2 Mounting Options
Mount below or above
Wall Mounted TV
Suitable For Sonos
This TV Sound Bar Mount is suitable for
most SONOS
sound bars
Attaches to TV VESA
Universal Mounting Arms attach to
the VESA holes on the TV and don't
require holes in the wall
Maximum Sound Bar Weight
This TV Sound Bar Mount supports
sound bars weighing up to 15kg
Hardware Kit Contents
Tools Required
• Adjustable spanner/socket set
• Phillips head screwdriver
®
, SONY & VIZIO
® ® ®
SAFETY FIRST
1. Ensure this instruction manual is completely read and understood
before attempting installation.
2. Some images in this guide may vary slightly from the actual
components supplied.
3. If used with products heavier than the rated weights indicated may
result in instability causing possible injury.
4. The Weight of the sound bar must be considered as part of the
Maximum Weight requirement of the TV Wall Mount unit in use.
5. Mounts must be attached as specified in assembly instructions.
Improper installation may result in damage or serious personal injury.
6. Safety gear and proper tools must be used. Installation of this TV
Sound Bar Mount will be easier with two people.
7. Use the mounting screws and bolts provided and DO NOT
OVERTIGHTEN mounting screws.
8. This product contains small items that could be a choking hazard if
swallowed. Keep these items away from children.
9. This product is intended for indoor use only. Using this product
outdoors could lead to product failure and personal injury.
10. If uncertain about any aspect of installation, contact The Crest
Company or any installation professional.
IMPORTANT:
- Ensure that you have received all parts according to the component
checklist prior to installation. If any parts are missing or faulty
contact your local distributor for a replacement.
- Retain these instructions for future reference.
MAINTENANCE:
- Check that the bracket is secure and safe to use at regular intervals
(at least every three months).
