Sony HCD-EP414 Service Manual

Sony HCD-EP414 Service Manual

Micro hi-fi component system

Advertisement

SERVICE MANUAL
Ver 1.0 2003. 06
HCD-EP414 is the Amplifier, CD player, Tape
Deck and Tuner section in CMT-EP414.
Amplifier section
European model:
DIN power output (rated): 11 + 11 W
(6 ohms at 1 kHz, DIN)
Continuous RMS power output (reference):
15 + 15 W
(6 ohms at 1 kHz, 10%
THD)
Music power output (reference):
25 + 25 W
Other models:
The following measured at AC 230 V or AC 120 V, 50/
60 Hz
DIN power output (rated): 11 + 11 W
(6 ohms at 1 kHz, DIN)
Continuous RMS power output (reference):
15 + 15 W
(6 ohms at 1 kHz, 10%
THD)
Inputs
MD IN (phono jacks):
Sensitivity 800 mV,
impedance 47 kilohms
Sony Corporation
9-877-473-01
2003F1678-1
Home Audio Company
© 2003.06
Published by Sony Engineering Corporation
HCD-EP414
Model Name Using Similar Mechanism
CD
Base Unit Name
Section
Optical Pick-up Name
TAPE
Model Name Using Similar Mechanism
Section
Tape Transport Mechanism Type
SPECIFICATIONS
Outputs
PHONES (stereo minijack):
Accepts headphones with
an impedance of 8 ohms or
more
SPEAKER:
Accepts impedance of 6 to
16 ohms.
CD player section
System
Compact disc and digital
audio system
Laser
Semiconductor laser
λ
(
=780 nm)
Emission duration:
continuous
Frequency response
2 Hz – 20 kHz (±0.5 dB)
Tape deck section
Recording system
4-track 2-channel stereo
Frequency response
50 – 13,000 Hz (±3 dB),
using Sony TYPE I
cassettes
MICRO HI-FI COMPONENT SYSTEM
AEP Model
E Model
Australian Model
HCD-EP515
BU-K7BD44B
KSM-213EDP
HCD-EP515
CMAL1Z240A
Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
Tuning range
87.5 – 108.0 MHz (50-kHz
step)
Antenna
FM lead antenna
Antenna terminals
75 ohms balanced
Intermediate frequency
10.7 MHz
AM tuner section
Tuning range
European model:
531 – 1,602 kHz
(with the tuning interval
set at 9 kHz)
Other models:
(with the tuning interval
set at 10 kHz)
531 – 1,602 kHz
(with the tuning interval
set at 9 kHz)
Antenna
AM loop antenna, external
antenna terminal
Intermediate frequency
450 kHz
— Continued on next page —
