Product Description
Frame:
6061 Aluminium alloy
Lightweight Folding Frame
Gears:
Acera 7 Speed – Shimano
Brakes:
Front and Rear Disc Brake
Stem:
Height Adjustable – Aluminium Alloy.
Front Fork:
High Strength – Aluminium alloy
Rim & Tire
20" x 13G x 36H alloy
Double wall with wide 4" Kenda tires
Seat Post:
Quick Adjust Clamp
Saddle:
VELO Wide Saddle
Motor:
36V / 250 W
Display:
LED / 5 Modes
Throttle:
Thumb Start
Battery:
36 V / 14 AH
Charger:
36V / 2A
Lights:
Front & Rear
(03) 8395 2616
(Thumb + PAS)
(Motor Power)
(6Kmh – Easy Start)
(Lithium Ion)
(Smart charger)
(Independent powered)
www.rilu-e-bike.com.au
Advertisement
Related Manuals for Rilu POGO 7D
Summary of Contents for Rilu POGO 7D
- Page 1 20” x 13G x 36H alloy Double wall with wide 4” Kenda tires GO 7-D Seat Post: Quick Adjust Clamp Saddle: VELO Wide Saddle RILU Trading Ptd Motor: 36V / 250 W (Thumb + PAS) POGO 7D Display: LED / 5 Modes...
- Page 2 60 - 70 Km Level 5 Motor Assist: 40 - 50 Km Battery charge time is 5-6 Hours Weight 20 Kg (Bike) net weight 24Kg (Battery Installed) POGO Rated Load weight is 120Kg (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
- Page 3 Product Summary General Usage Summary Congratulation on your purchase of a RILU POGO 7D RILU recommends you first ride the bike without using any Folding electric bicycle. electrical assistance to familiarize yourself with the mechanical gearing and breaking system of your POGO.
- Page 4 Default PAS MODE Reduce Assist to ‘0’ while moving/pushing your pogo “low” to avoid any sudden unexpected movement. Turn “ON” LCD backlight Reset - Trip Meter Hold “ + & M ” HOLD “+“ (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
- Page 5 The gauge will correct itself after the heavy load is lifted. Only use ‘Walk Assist’ when you are walking the bike up and incline, do not use while sitting on the bike. Hold “ - ” (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
- Page 6 CHECK MOTOR CABLE MOTOR HALL CHECK MOTOR CABLE EABS SENSOR ON CHECK BRAKE CABLE BATTERY LOW RECHARGE BATTERY MOTOR STALL CHECK MOTOR / BRRAKES CONTROLLER COMMUNICATION ERROR CHECK CABLES DISPLAY COMMUNICATION ERROR CHECK CABLES (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
- Page 7 HOLD “ - ” Reduces risk of damaged during transport and storage Step 2 - Align the pedals Step 4 - Pull ‘Folding Lever’ forward Chain ring – Pointing to the front of the bike. (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
- Page 8 Over time you may need to adjust the folding clamp if you are unable to fully close the clamp before riding or if the folding lock is loose and doesn’t grip the frame. LOOSEN TIGHTEN Step 6 - Folded POGO (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
- Page 9 Adjusting - Gear Quick Adjustment If you experience uneven shifts or slippage in the lower gears, where RILU advises using a bike service stand when performing gearing and the chain jumps from gear #2 to gear #3 unintentionally. Try to adjust breaking adjustments as it will be easier when the bike is raised off the the derailleur using the following method to improve shifting.
- Page 10 Gearing Adjustment – Gear #7 Pulley Alignment Gearing Adjustment – Gear #1 Pulley Alignment (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
- Page 11 Motor - Change Tire Motor – Service Notes Step 1 Step 2 Cut - Cable Tie Unplug - Motor Cable Step 3 Step 4 18mm Spanner Pull back derailleur Step 5 Wheel nut arrangement (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
- Page 12 (UP) button on the Display to activate 6Km/h walk function Step 4 - If the motor works using 6km/h but does not when pedalling in PAS 1 – 5 you may have a damaged pedal assist sensor. (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
- Page 13 Step 5 - Check the pedal assist cable is not damaged from impact. Thumb Throttle – Location & Function RILU advises riders to avoid ‘hard starts’ that involve applying full throttle while on an incline. RILU recommends having the bike in motion before engaging the throttle to prolong the life of the motor.
- Page 14 (03) 8395 2616 (03) 8395 2616 www.rilu-e-bike.com.au www.rilu-e-bike.com.au...
- Page 15 (03) 8395 2616 www.rilu-e-bike.com.au...
