Zoom 5821F Quick Start Manual

T W O - P O R T A T A
Your Two-Port ATA comes with a power cube and
Ethernet cable. Some models also include other items,
such as a phone cord, phone-jack adapters, phone filter,
or service provider flyer.
Quick Start
To complete the installation, you need the following:
• A broadband Internet connection using a cable
modem, ADSL, T1, E1, SDSL, or any other high-speed
"always on" Internet connection.
• An account set up with a VoIP service provider. If
you do not have an account set up, please look for a
Read Me First! flyer in the box for your VoIP Two-Port
ATA and follow its instructions. If there is no flyer, go to
your service provider's Web site and sign up for service.
• A router that uses your broadband Internet
connection. This can be an ADSL modem with a built-
in router, a cable modem with a built-in router, or some
other router connected to a broadband Internet
connection. The router needs at least one available
LAN port, and the router needs to be set up for 10/100
or 10/100/1000 or 10 Mbps. (Most routers use 10/100
unless you change them.)
• A telephone or telephones so you can place and
receive phone calls.
Now you're ready to connect the Two-Port ATA to
telephones, a router, and a "live" power outlet.
Follow these easy steps:
1 1 1 1
Plug your telephones or cordless phone base stations
into the PHONE jacks on the left side of the ATA's
back panel. You can use either one of the phone
jacks or both:
