Bionics BCM-600 Manual

Electrocardiograph
Hide thumbs
Table of Contents

Advertisement

Quick Links

Head Office/Factory
687-5, Sangoan-ri, Hongcheon-eup, Hongcheon-gun,
Gangwon-do, Korea (zip.250-804)
Tel : + 82-33-434-9041
Fax : + 82-33-434-9043
Seoul Office/R&D
1406, Masters Tower, 553, Dohwa-dong, Mapo-gu,
Seoul, Korea (zip.121-748)
Tel : + 82-2-714-2960∼2
Fax : + 82-2-714-2963
Customer Service Dept.
Tel : + 82-2-714-2962
Fax : + 82-2-714-2963
Address of Region Representative
ET MEDICAL DEVICES SPA
VIA DE ZINIS 6, 38011 CAVARENO (TN) ITALY
Tel : + 39 0463 85 01 25
Fax : + 39 0463 85 00 88
Operation Manual
BCM- 600
Electrocardiograph ( Ver 1.0 )

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BCM-600 and is the answer not in the manual?

Questions and answers

Related Manuals for Bionics BCM-600

Summary of Contents for Bionics BCM-600

  • Page 1 Operation Manual BCM- 600 Electrocardiograph ( Ver 1.0 ) Head Office/Factory 687-5, Sangoan-ri, Hongcheon-eup, Hongcheon-gun, Gangwon-do, Korea (zip.250-804) Tel : + 82-33-434-9041 Fax : + 82-33-434-9043 Seoul Office/R&D 1406, Masters Tower, 553, Dohwa-dong, Mapo-gu, Seoul, Korea (zip.121-748) Tel : + 82-2-714-2960∼2 Fax : + 82-2-714-2963 Customer Service Dept.
  • Page 2 OPERATION MANUAL BCM-600 Electrocardiograph ( Ver 1.0 ) ( OCT. 26. 2010 )

  • Page 3: Table Of Contents

    2. Contacts 3. Product Guarantee 4. Symbols in the Manual 5. Precautions for use 6. Precations for Electrical Safety 7. Characteristics and Principles of BCM-600 8. Composition of BCM-600 9. How to set BCM-600 Precations for Settings Checkpoints Before Use Maintenance and Cleaning After Use 10.

  • Page 4: Before Using The Product

    BCM-600 Before Using the Product Thank you for purchasing BCM-600 For safe and efficient operation, please read the manual to learn about the functions of the product before use. 16. How to use RECORDS Please keep this manual nearby to assist you with operating the functions of the product.

  • Page 5: Product Guarantee

    Electrocardiograph (Ver 1.0) BCM-600 Product Guarantee Symbols in the Manual Some symbols are used in this manual to help users or patients use this product safely and The product you have purchased comes with a 1-year warranty from the purchasing date appropriately and to prevent any risk to patients or damage to materials.
  • Page 6 Electrocardiograph (Ver 1.0) BCM-600 Operational Do’ ’ s and Don’ ’ ts Do not operate or store the equipment under the following environments. Locations exposed to chemical Make sure to prevent dust, especially or explosive gases. metal debris, from penetrating in.

  • Page 7: Precations For Electrical Safety

    Is the product supplied with the appropriate power? (100~240VAC) Are all connecting parts (power cables or the product) properly connected? ◈ If you want to turn off the BCM-600 while you’re operating, please use the power switch Is the product completely grounded? (If not, noise may occur.) where is the front of the product.

  • Page 8: Characteristics And Principles Of Bcm-600

    BCM-600 provides the various diagnosis by Auto-Diagnosis BCM-600 can be used in transport by the built-in-rechargeable battery. BCM-600 can be used effectively in ECG chart management with the printed paper including Adapter(1EA) Operation Manual the patient’s information and user’s information...

  • Page 9: How To Set Bcm-600

    A. Keep the product cleans by cleaning it using a soft cloth at least once a month. Do not use - Use BCM-600 under conditions of 10℃∼45℃ of circumstantial temperature and 30％∼85％ thinner, ethylene, oxidant or lacquer since these may damage the product.

  • Page 10: Components Of Bcm-600

    (11) PAPER Cover (4) LAN Port (For Upgrade) (12) AC Power LED (5) Power Adapter (5) PRINT START Button (6) SPEED Button (13) DC Power LED (6) Potential equalization stud (7) EXIT Button 14 Components of BCM-600 Components of BCM-600 15...

  • Page 11: Description Of Product Symbols

    Electrocardiograph (Ver 1.0) BCM-600 3. Description of Product Symbols (1) Screen Configuration Symbol Comments Symbol Description Type CF Product, Screen Shift Defibrillation protected Power stand-by switch Wave Freeze Start Printing (Printer) Wave speed change Attention, consult accompanying Wave size change...

  • Page 12: How To Set Bcm-600

    Chest Electrode (C6) lead check Normal (Green) Abnormal(Red) displayed. Auto diagnosis Flickers at 1-second interval. Printing Flickers at 1-second interval. Waveform stop Flickers at 1-second interval. AC in use Fixed. Battery in use Fixed. 18 Description of Product Symbols How to Use BCM-600 19...

  • Page 13: Menu Setting

    Return EXIT Lead of BCM-600 provides the 4 kinds of screen EKG channel conversion can be done by press the Lead key After moving to Menu you want to change, by rolling to left or right the Menu button, you can select the Menu by press (the triangle on the right side of Menu means that there are more - 4 different configurations are as below;...

  • Page 14: Other Menu Setting

    Electrocardiograph (Ver 1.0) BCM-600 (2) Other Menu setting PRINT Menu Changeable Range Description MONITOR : Patient’s ▶ Please refer the below table for the other menu information, WAVE display MONITOR DIAGNOSIS : Patient’s EKG Menu Changeable Range Description MODE DIAGNOSIS...

  • Page 15: Default Set

    Electrocardiograph (Ver 1.0) BCM-600 (3) Default setting PRINT Menu Changeable Range Description NAME Within 16 characters Patient’s name setting ▶ The default settings of the values can be used, without the need of changing the setting values Within 16 characters Patient’s Serial no.

  • Page 16: Print

    ◈ When you save a printed data, don't remove an USB Flash Memory until the save progress is complete. Please refer the below table for the contents of other PRINT Menu. ◈ Please use an USB Flash Memory listed in 'BCM-600 Viewer Manual'. If not, it may PRINT Menu Changeable Range Description cause malfunction of the product.

  • Page 17: How To Use Records

    Electrocardiograph (Ver 1.0) BCM-600 How to use RECORDS ◈ BCM-600 has stored the late 30pcs of printed data MENU PRINT MENU MODE ▶ ▶ Select RECORDS on Print Menu by PRINT WAVE SIZE ▶ ▶ press Menu button PATIENT BRIGHTHESS ▶...

  • Page 18: Power & Battery Specifications

    ◈ When the battery is removed, all data can be reset. Only in case the product is kept for long Both AC and DC power is used for BCM-600. Basically, AC power is used and a rechargeable time, Remove the battery from the product battery is available for portable use.

  • Page 19: Ekg Measurement

    Attach the patient’s electrode to the sites shown below. BCM-600 records the patient’s ECG by press printer button BCM-600 analyzes and prints the cumulated ECG data for 10 seconds. “Please wait” will be appeared in case the ECG data are cumulated within 10seconds.

  • Page 20: Before Requesting After Sale Service

    Electrocardiograph (Ver 1.0) BCM-600 ▣ Problems in Printer (OPTION) Before Requesting After-Sales Service Sign How to treat This section shows how to treat simple problems encountered during use. 1. Check if the printer icon blinks on the screen. Please check the following points before requesting after-sales service No printing 2.

  • Page 21: Product Specifications

    Electrocardiograph (Ver 1.0) BCM-600 3) Physical Specifications Product Specifications - Power requirements : AC 100 ~ 240V, 50/60Hz - Power consumption : 50VA(MAX) 1) Features - Battery: LI-Ion , 11.1V , 4400mAh - LCD Graphic Display 800 X 480 dots, 3x1/3x2/6x1/6x2...

  • Page 22: Product Warranty

    Fax) Name of Distributor Name of Manufacture BIONICS Co., Ltd. Thank you for using BCM-600 This product is a medical device. Only the products that have Passed our extensive and thorough quality tests are offered to our customers Our policies on repairing, exchange and refund complies with “Regulation on Consumer Protection &...
