Fume Collector for Welding
Operation Manual & Cautions
Thank you for purchasing Fumeresa from Showa Denki. This manual explains the specifications for
the [Fumeresa FRM-H15].
Please read the oprating instruction and cautionary information carefully to ensure that the Fumeresa
is used in a safe and efficient manner. Special attention should be given to cautionary information
which bears [
] the mark.
Keep this manual in a secure location where it can be easily
accessed
1. Safety precautions ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・
2. Item to check at product delivery ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・
【Contents】
・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・
・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・
・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・
・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・
・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・
・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・
・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・
information・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・
0522（E）-B
1
1
2
2
3
3
4-5
5
6
6
6
Advertisement
Table of Contents
Related Manuals for Showa Denki FUMERESA FRM-H15
Summary of Contents for Showa Denki FUMERESA FRM-H15
- Page 1 0522（E）-B Fume Collector for Welding Operation Manual & Cautions Thank you for purchasing Fumeresa from Showa Denki. This manual explains the specifications for the [Fumeresa FRM-H15]. Please read the oprating instruction and cautionary information carefully to ensure that the Fumeresa is used in a safe and efficient manner.
- Page 2 1. Safety precautions indicates that there is a possibility of [an accident leading to death Warning or serious injury] or [fire occurrence] if mishandled. indicates things that lead to [accident leading to injury] and Caution [product damage] if mishandled. Warning Careless use of this machine could result in serious injury or accidents.
- Page 3 3. Name of each parts ② ① ③ ④ ⑤ ⑥ ⑩ ⑨ ⑧ ⑦ Name Name ① ⑥ Blower Plug ② ⑦ Flexible arm Caster rear wheel ③ ⑧ Silencer Caster front wheel (with stopper) ④ ⑨ Manometer Tank ⑤...
- Page 4 5．Precautions (1) Please install indoor horizontal location. Do not get water or oil. (2) Do not move while the flexible arm extended (3) Please check the manometer value and clean the filter regularly. ※For the cleaning method, please refer to page 4 section [7.
- Page 5 7. Maintenance and inspections Flexible arm ※ Please read the instruction manual attached separately and use it properly. Make sure that the suction port of the hood is not blocking by dust or foreign matter. It may cause the suction capacity decrease. Do not use the duct part that has damage or deterioration.
- Page 6 How to adjust the manometer Make sure that the needle (black) points to "0" when the switch is off. If did not point to "0", adjust with the "zero set knob" in Fig. 2. The ponter (red) is set to approximately 1.5 kPa. (initial stage) When changing, please adjust with "Pointer adjustment knob".
- Page 7 The above points are specified based on use in Japan. When using this unit in countries other than Japan, consult with our branches or sales offices in advance. 11．Contact information Contact the following department regarding specifications and technical questions. Showa Denki CO., LTD, Daito Factory, Business Promotion Dept. TEL: +81-72-870-5708 FAX: +81-72-870-7243 E-mail: sales@showadenki.co.jp...
- Page 8 Oversea Sales Department 1-25 Shinden Kitamachi, Daito City, Osaka 574-0052 ☎ +81-72-871-1511 ＦＡＸ +81-72-870-7243 SHOWA DENKI (THAILAND) CO., LTD No1/46 Soi2 Grand De Ville, Soi Supapong 1 (Soi Srinakarin 42), SriNakarin Road Nongbon, Pravet Bangkok, Thailand 10250 ☎ +66-2-330-8798 FAX +66-2-330-8799 SHOWA DENKI (KOREA) CO., LTD.
