Odev TOMO User Manual page 9

main
The Final Look of Tomo the Tricycle
screw M4 × 6mm
control
box
After completing step 11, please
see page 5 and then 6 to install the
batteries and connect the wires.
Go to page 6 to see wiring instructions
Step 12: install the main control box
Dicycle Assembly Procedure
corner plate
screw M3 × 6mm
motor
Step 1: install the right and left motor
Dicycle Assembly Procedure
copper
screw M4 × 6mm
coupling
Step 2: install the right and left coupling
