Odev TOMO User Manual page 5

Battery User Guide
Battery User Guide
Please follow the user guide:
1. Use only the standard size AA batteries (6pcs).
2. Do not mix old and new batteries; do not mix the batteries with
different brands; do not mix the batteries with different types.
3. If the performance of the Tricycle or Dicycle is slow, it could mean
that the battery is low. Please replace the batteries.
4. If the robot is put in idle for a long time, please take out the batteries.
5. After each use, please turn off the power to prevent energy lost.
6. When installing the batteries, please make sure the positive and
negative sides of the batteries are installed correctly.
Remove the Main Control Box
Disconnect all the wires
Press down the tail part of the control box
While pressing down, push the box towards to the back
Lift the box to remove
Replace the Battery
Remove the Main Control Box to
replace the batteries
Socket
Install the Main Control Box
Align the control box to its base as shown
Slide the control box towards to the front
Wiring Diagram
ultrasonic sensor
Wiring Diagram
tracking sensor
motor
motor
