4
.
2
W
a
l
l
-
M
o
u
4
.
2
W
a
l
l
-
M
o
u
The Vigor 166 modem has keyhole type mounting slots on the underside for
secure wall mounting.
1.
A template is provided on the Vigor160 series packaging box to enable you to
space the screws correctly on the wall.
2.
Place the template on the wall and drill holes at the marked points.
3.
Fit screws into the wall using the appropriate type of wall plug.
Note
4.
Fit the Vigor 166 modem onto the protruding screwheads and lower the
modem to affix it securely in place on the wall.
n
t
e
d
I
n
s
t
a
l
l
a
t
n
t
e
d
I
n
s
t
a
l
l
a
The recommended drill bit diameter is 6.5mm (1/4").
i
o
n
t
i
o
n
5
